Parameterising analog modules
Signal functions of 4xanalog input
13
Parameter setting via PROFIBUS−DP
13.1
13.1.4
L
13.1−9
EDSPM−TXXX−9.0−11/2009
Paramete
r bytes
2/3/4/5
Tolerance
2)
Format
1)
Signal rangeSignal function
2F
h
Current
measurement
±20 mA
−20.00
−16384
{0.01 mA}
{1
dec
}
+20.00
16384
S5
Sum and sign
±0.05 % of
the final value
Min. Limit
values
Max.
−23.70 mA
−19456
dec
+23.70 mA
+19456
dec
32
h
Resistance
measurement with
four−wire
connection
6000 W 0.00
0
{0.01 W}
{1
dec
}
+6000.00
32767
dec
S7
±0.05 % of
the final value
33
h
6000 W 0.00
0
{0.01 W}
{1
dec
}
+6000.00
6000
dec
±0.05 % of
the final value
35
h
60 W 0.00
0
{0.01 W} +60.00
6000
dec
±0.2 % of the
final value
3)
36
h
600 W 0.00
0
{0.01 W}
{1
dec
}
+600.00
6000
dec
±0.1 % of the
final value
3)
37
h
3000 W 0.00
0
{0.01 W}
{1
dec
}
+3000.00
30000
dec
±0.1 % of the
final value
3)
38
h
6000 W 0.00
0
{0.01 W}
{1
dec
}
+6000.00
6000
dec
±0.1 % of the
final value
3)
3A
h
Current
measurement
±20 mA
−20.00
−16384
{0.01 mA}
{1
dec
}
+20.00
16384
S5
Two’s
complement
±0.05 % of
the final value
Min. Limit
values
Max.
−23.70 mA
−19456
dec
+23.70 mA
+19456
dec
3Bh Voltage
measurement
±10 V
−10.00
−16384
{0.01V}
{1
dec
}
+10.00
16384
S5
Two’s
complement
±0.2 % of the
final value
Min. Limit
values
Max.
−12.50 V
−20480
dec
+12.50 V
20480
dec
3D
h
Resistance
measurement with
four−wire
connection
60 W 0.00
0
{0.01 W}
{1
dec
}
+60.00
6000
dec
S7
±0.1 % of the
final value
3E
h
600 W 0.00
0
{0.01 W}
{1
dec
}
+600.00
6000
dec
±0.05 % of
the final value
3F
h
3000 W 0.00
0
{0.01 W}
{1
dec
}
+3000.00
30000
dec
±0.05 % of
the final value
57
h
Voltage
measurement
0 ... 50
mV
0.00
0
{0.01 mV}
{1
dec
}
+50.00
5000
S7
Two’s
complement
±0.1 % of the
final value
Min. Limit
values
Max.
0.00
0
+59.25 V
5925
dec
58
h
Voltage
measurement
±10 V
−10.00
−10000
{0.01V}
{1
dec
}
+10.00
10000
S7
Two’s
complement
±0.05 % of
the final value
Min. Limit
values
Max.
−11.85 V
−11850
dec
+11.85 V
11850
dec
59
h
Voltage
measurement
±4 V
−4.00
−4000
{0.01V}
{1
dec
}
+4.00
4000
S7
Two’s
complement
±0.05 % of
the final value
Min. Limit
values
Max.
−4.74 V
−4740
dec
+4.74 V
4740
dec
