Parameterising analog modules
Signal functions 4xanalog input ±20mA
13
Parameter setting via PROFIBUS−DP
13.1
13.1.6
L
13.1−13
EDSPM−TXXX−9.0−11/2009
Paramete
r bytes
2/3/4/5
ToleranceFormat
1)
Signal rangeSignal function
39
h
Current
measurement
4 ... 20
mA
4.00
0
{0.01 mA}
{1
dec
}
20.00
16384
S5
Two’s
complement
±0.2 %
2)
±0.5 %
3)
Min. Limit
values
Max.
0.8 mA
−3277
dec
+24.00 mA
+20480
dec
3A
h
Current
measurement
±20 mA
−20.00
−16384
{0.01 mA}
{1
dec
}
+20.00
16384
S5
Two’s
complement
±0.1 %
2)
±0.2 %
3)
Min. Limit
values
Max.
−25.00 mA
−20480
dec
+25.00 mA
+20480
dec
FF
h
Analog input deactivated
1)
Format of the input data ( 13.1−6).
2)
Tolerance of the input range at an ambient temperature of 25 °C.
3)
Tolerance of the input range across the entire admissible temperature range.
