Lenze EPM-T1 Series - Page 519

Index table
15
Appendix
15.1
L
15.1−5
EDSPM−TXXX−9.0−11/2009
Index ImportantPossible settingsName
SelectionLenze
I1407
h
¿
Index is only available in the modular
system
 8.3−3
1 COB−ID used by
RxPDO 8
1280 385 {1} 2047 Defining the individual identifiers for
process data object 8
2 Transmisson type 255
0 {1} 255 Defining the transmission mode
0 ... 240 Process data update on sync telegram
transmission
The input data are accepted on sync
telegram transmission.
241
... 254
Reserved
255 Process data update on occurrence of an event Every received value is accepted
I1408
h
¿
Index is only available in the modular
system
 8.3−3
1 COB−ID used by
RxPDO 9
1344 385 {1} 2047 Defining the individual identifiers for
process data object 9
2 Transmisson type 255
0 {1} 255 Defining the transmission mode
0 ... 240 Process data update on sync telegram
transmission
The input data are accepted on sync
telegram transmission.
241
... 254
Reserved
255 Process data update on occurrence of an event Every received value is accepted
I1409
h
¿
Index is only available in the modular
system
 8.3−3
1 COB−ID used by
RxPDO 10
1665 385 {1} 2047 Defining the individual identifiers for
process data object 10
2 Transmisson type 255
0 {1} 255 Defining the transmission mode
0 ... 240 Process data update on sync telegram
transmission
The input data are accepted on sync
telegram transmission.
241
... 254
Reserved
255 Process data update on occurrence of an event Every received value is accepted
I1600
h
¿
Mapping parameters for receive PDOs
0 Number of mapped
RxPDO1
0 {1} 255 8 bit value
1 1st mapped object 00000000
h
{1} FFFFFFFF
h
32 bit value
2 2nd mapped object 00000000
h
{1} FFFFFFFF
h
32 bit value
3 3rd mapped object 00000000
h
{1} FFFFFFFF
h
32 bit value
4 4th mapped object 00000000
h
{1} FFFFFFFF
h
32 bit value
5 5th mapped object 00000000
h
{1} FFFFFFFF
h
32 bit value
6 6th mapped object 00000000
h
{1} FFFFFFFF
h
32 bit value
7 7th mapped object 00000000
h
{1} FFFFFFFF
h
32 bit value
8 8th mapped object 00000000
h
{1} FFFFFFFF
h
32 bit value
