4×analog output 0...20mA
4
The modular system
4.19
L
4.19−3
EDSPM−TXXX−9.0−11/2009
Type
4×analog output 0...20mA
Voltage supply DC 5 V / 60 mA (via backplane bus)
External voltage supply DC 24 V / 50 mA (DC 19.2 ... 28.8 V)
Connectable cable cross−section £ 2.5 mm
2
(³ AWG 14)
Analog outputs
Number 4 outputs
Analog−to−digital converter 12 Bit
Output range
Current 0 ... 20 mA
4 ... 20 mA
Information on tolerances can be
found in the chapter "Parameter
setting"
Actuator − input resistance > 350 W
Delay time per channel 450 ms
Electrical isolation from backplane bus Yes, via optocouplers
Communication
Output data 8 bytes (2 bytes per analog output)
Dimensions
Width 25.4 mm
Height 76.0 mm
Depth 76.0 mm
Weight 100 g
Order number EPM−T322
Technical data
