Installaon of shield c
onnecon sheet for motor cable 30 kW to 45 kW
P 2Z
1.7 Nm
(15 lb-in)
Installaon of shield c
onnecon sheet for motor cable 55 kW to 110 kW
6 Nm
53.1 lb-in
4 x TX 25
6 x
~
TX 20
❶
❷ ❸
❹
4 x TX 25
Dimensions
The specied ins
tallaon clearances are minimum dimensions to ensure a
sucient air circulaon for cooling purposes. They do not consider the bend
radiuses of the connecng cables.
