Electrical ins
tallaon
Important notes
DANGER!
Danger to life due to electric shock!
Dea
th or serious injuries
▶
Deenergize the inverter before working on the inverter.
▶
Inverter up to 45 kW (60 hp): Aer switching o the mains voltage, wait for at least 5
minutes before you start working.
▶
Inverter from 55 kW (75 hp): Aer switching o the mains voltage, wait for at least 20
minutes before you start working.
DANGER!
Dangerous electrical voltage
The leak
age current against earth (PE) is > 3.5 mA AC or > 10 mA DC.
Possible consequences: Death or severe injuries when touching the device in the event of an
error.
▶
Implement the measures requested in EN 61800−5−1 or EN 60204−1. Especially:
▶
Fixed installaon
▶
The PE connecon must comply with the standards (PE conductor diameter ≥ 10 mm
2
or
use a double PE conductor)
WARNING!
Dangerous electrical voltage
De
vice error causes an overvoltage in the system.
▶
For a voltage supply with DC 24 V (± 20 %), use only a safely separated power supply unit
according to the valid SELV/PELV requirements.
EMC-compliant ins
tallaon
The drive system (inverter and drive) only complies with the EMC Direcve 2014/30/EU if it is
installed according to the guidelines for CE-typical drive systems.
These guidelines should also be followed in installaons requiring FCC Part 15 or ICES 001
compliance.
EMC-compliant installaon must be implemented with shielded motor cables with low
capacitance.
Capacitance per unit length:
•
C-core-core/C-core-shielding: < 75/150 pF/m ≤ 2.5 mm² (≥ AWG 14)
•
C-core-core/C-core-shielding: < 150/300 pF/m ≥ 4 mm² (≤ AWG 12)
Electrical ins
tallaon
Important notes
127
