Networks
onboar
d EtherCAT
Typical topologies
Line
IN OUT
M
R
SDn
SD2
SD1
IN OUT IN
M Master
SD Slave Device
Bus-related in
formaon
Designaon On-board EtherCAT
Communicaon medium Ethernet 100 Mbps, full duplex
Use Connecon of the inverter to the system
bus cross communicaon or as standard
EtherCAT slave
Status display 1 LED (RUN)
Connecon designaon IN: X236
OUT: X237
EtherCAT
T
ypical topologies
Line
IN OUT
M
R
SDn
SD2
SD1
IN OUT IN
M Master
SD Slave Device
Connecon descripon EtherCAT
Connecon X246 X247
Connecon type RJ45
EtherNet/IP
T
ypical topologies
Line Tree Ring
S
R
An
A2A1
S
SWn
SW2
SW1
S
An
A2
A1
A3
DLR
S Scanner SW Switch
A Adapter
Electrical ins
tallaon
Networks
onboard EtherCAT
158
