Lenze I95AE222F Mounting And Switch-On Instructions

3-phase mains c
onnecon 230/240 V
Rated data
These inverters do not have an integrated RFI lt
er in the AC mains supply.
In order to meet the EMC requirements according to EN 61800−3, an external
EMC lter according to IEC EN 60939 must be used.
The user must verify that the conformity with EN 61800−3 is fullled.
Inverter I95AE
137D 155D 175D 215D 222C 240C 255C
Rated power P
rated
kW 0.37 0.55 0.75 1.5 2.2 4 5.5
Rated power P
rated
hp 0.5 0.75 1 2 3 5 7.5
Mains voltage range 3/PE AC 195 V ... 264 V, 45 Hz ... 65 Hz
Output voltage 3 AC 0 - 230/240 V
Rated mains current
without mains choke A 3.9 4.8 6.4 9.5 - 20.6 28.8
with mains choke A 3 3.8 5.1 6.8 9.8 15.7 21.9
Apparent output power kVA 0.9 1.2 1.6 2.6 3.6 6.2 8.7
Rated output current
2 kHz A 2.4 3.2 4.2 7 9.6 16.5 23
4 kHz A 2.4 3.2 4.2 7 9.6 16.5 23
8 kHz A 2.4 3.2 4.2 7 9.6 16.5 23
16 kHz A 1.6 2.1 2.8 4.7 6.4 11 15.3
Power loss
2 kHz W 34 39 48 73 96 151 207
4 kHz W 35 42 53 81 107 172 235
8 kHz W 40 47 61 98 130 211 293
16 kHz W 40 47 61 98 130 211 293
Cyclic mains switching 3 mes per minute
Max. motor cable length
shielded
without EMC category m 50 100
Category C1 (2 kHz, 4 kHz,
8 kHz)
m -
Category C2 (2 kHz, 4 kHz,
8 kHz)
m -
Category C3 (2 kHz, 4 kHz,
8 kHz)
m 50
Weight m kg 1.6 3.9
Weight m lb 3.5 8.6
Technical data
3-phase mains c
onnecon 230/240 V
Rated data
175
