Electrical connection
Leuze electronic GmbH + Co. KG BPS 307i 47
Switching input/output
The BPS is equipped with two, freely programmable, optically decoupled switching inputs/outputs, SWIO1
and SWIO2.
• The switching inputs can be used to activate various internal functions of the BPS (e.g., Measurement
Stop/Start, Teach Preset, Reset Preset).
• The switching outputs can be used to signal the state of the BPS and to implement external functions
independent of the superior control (e.g. position value/speed value invalid, position and speed limit
value exceeded, device error).
• The control can use switching inputs/outputs as digital I/Os.
If no internal BPS function is connected to the switching inputs/outputs, the ports can be addressed as
two inputs, two outputs or as one input and one output of a digital I/O component.
NOTICE
The function as input or output is set via the webConfig configuration tool (CONFIGURATION >
DEVICE > Switching inputs/outputs, see chapter 9.3.4 "CONFIGURATION function").
NOTICE
Maximum input current
Ä The input current of the respective switching input is maximum 8mA.
NOTICE
Maximum loading of the switching outputs
Ä Do not load the respective switching output of the BPS with more than 60mA at
+18…30VDC in normal operation.
Ä Each configured switching output is short-circuit proof.
NOTICE
The two switching inputs/outputs, SWIO1 and SWIO2, are configured as follows by default:
Switching output SWIO1: Position value invalid
Switching input SWIO2: Teach Preset
NOTICE
SWIO1 and SWIO2 as switching output
Ä At the outputs of the BPS (SWIO1 and SWIO2), no switching outputs may be connected
from external sensors/devices.
The switching output of the BPS may otherwise malfunction.
