Leuze BPS 307i - SSI Connection Cable; Service USB

Electrical connection
Leuze electronic GmbH + Co. KG BPS 307i 49
7.5.3 SSI connection cable
Tab.7.3: SSI connection cable KB307
KB 307-3000 KB 307-10000 FLEX Designation Assignment
WH GY FE Functional earth
WH-BK WH GNDIN Negative supply voltage
(0VDC)
BK BN VIN +18…+30VDC supply
voltage
GY VT SWIO1 Sw. input/output 1 (con-
figurable)
WH-GN BK SWIO2 Sw. input/output 2 (con-
figurable)
WH-YE BU CLK- -Clock line SSI
(Input electrically iso-
lated)
WH-RD GN DATA- -Data line SSI
(Output electrically iso-
lated)
YE RD CLK+ +Clock line SSI
(Input electrically iso-
lated)
RD YE DATA+ +Data line SSI
(Output electrically iso-
lated)
--- PK Not connected
VT --- Reserved ---
WH-BN --- Reserved ---
BN --- Reserved ---
WH-OG --- Reserved ---
OG --- Reserved ---
GN --- Reserved ---
BU --- Reserved ---
7.5.4 Service USB
NOTICE
PC connection!
Ä The service USB interface of the BPS can be connected to the USB interface on the PC with
a standard USB cable (plug combination - Mini-B type / Type A).
Ä If possible, use the specific USB service cable from Leuze (see chapter 14.3 "Cables acces-
sories").
5-pin, Mini-B plug for connecting to the service USB.
