Device description
Leuze electronic GmbH + Co. KG BPS 307i 17
NOTICE
Laser activation by selecting Quality!
Ä If the position measurement has stopped and the laser thereby switched, the laser is
switched on and the position measurement started by activating Quality.
The display is controlled via the control buttons:
• 
–Enter: activate or deactivate the display shift function
• 
–Down: scroll through functions (downwards)
Example: Representation of the I/O status on the display
1. Press button
: Display flashes
2. Press button
: Display changes from position value (Position Value) to reading quality (Quality)
3. Press button
: Display changes from reading quality (Quality) to device status (BPS Info)
4. Press button
: Display changes from device status (BPS Info) to I/O Status
5. Press button
: I/O Status displayed, display stops flashing
Display during device start-up
During device start-up, a start-up display first appears which is briefly followed by the display with the ver-
sion information.
The standard display after starting up the BPS is Position Value.
3.4 Bar code tape
3.4.1 General information
The barcode tape is available in different variants:
• BCBG40… barcode tape with 40mm grid
Code128 with character setC, increasing in increments of 4 (e.g., 000004, 000008, …)
• BCBG30… barcode tape with 30mm grid
Code128 with character setC, increasing in increments of 3 (e.g. 000003, 000006, …)
A barcode tape consists of a sequence of individual position labels in one of the two grids. Defined cut
marks are provided for cutting the BCB.
The BCB is delivered on a roll. A roll contains up to 300m of BCB, with the wrapping direction from the out-
side to the inside (smallest number on the outside). If more than 300m of BCB is ordered, the total length
is divided into rolls of max. 300m.
Standard bar code tapes in fixed length increments as well as special bar code tapes with custom tape
start value, tape end value, custom length and height can be found on the Leuze website in the acces-
sories for the BPS300 devices.
An entry wizard is available for special bar code tapes on the Leuze website under devices BPS300 - Ac-
cessories tab. The entry wizard provides support when entering the individual pieces of tape data and cre-
ates a query or order form with the correct part number and type designation.
NOTICE
Only one BCB type per system!
Ä In a given system, use either only BCBG30… with 30mm grid or only BCBG40… with
40mm grid.
If different BCBG30… or BCBG40… models are used in one system, the BPS cannot en-
sure an exact position determination.
