Care, maintenance and disposal
Leuze electronic GmbH + Co. KG BPS 307i 74
• BCBG40: 1m of barcode tape is provided on each A4 sheet.
• Five lines of20cm with five code-information sections of 40mm each
• Tape lengths: from 0 to 9999.99m in various files; each 500m
Replacing a section of defective barcode tape
Ä Determine the coding of the defective area.
Ä Print out the coding for the given area.
Ä Affix the printed code over the defective section of barcode tape.
NOTICE
Printing coding
Ä Select only those pages that are actually required.
Ä Change the printer settings so that the barcode is not distorted.
Ä Check the print results and measure the distance between two barcodes: BCBG40…:
40mm and BCBG30…: 30mm. See graphics below.
Ä Cut the code strips and arrange them next to one another. The code content must always in-
crease or decrease in increments of 30mm or 40mm. Check that the printed values in-
crease by 3 (BCBG30…) or 4 (BCBG40…).
000040 000044 000048 000052
40
G40Leuze G
40Leuze G40Leuze G40Leuze
Fig.11.1: Checking the print result – BCBG40…-repair kit (40mm gird)
000018 000021 000024 000027 000030
30
G30LeuzeG30LeuzeG30LeuzeG30LeuzeG30Leuze
Fig.11.2: Checking the print result – BCBG30…-repair kit (30mm gird)
11.3 Disposing
Ä For disposal observe the applicable national regulations regarding electronic components.
