Technical data
Leuze electronic GmbH + Co. KG BPS 307i 87
13.5 Dimensioned drawing barcode tape
000040 000044 000048
38,72
47 ±0,3
1,28
G40Leuze G40Leuze G40Leuze
all dimensions in mm
Fig.13.13: Dimensioned drawing BCBG40… barcode tape with 40mm grid
000018 000021 000024
28,72
47 ±0,3
1,28
G30Leuze G30Leuze G30Leuze
all dimensions in mm
Fig.13.14: Dimensioned drawing BCBG30… barcode tape with 30mm grid
