Starting up the device – Basic configuration
Leuze electronic GmbH + Co. KG BPS 307i 53
8.1.2 Setting the configuration of the SSI interface
Ä Set the parameters of the SSI interface via the webConfig tool or via connection hood MS307 or
MK307.
NOTICE
Devices with connection hood KB307 can only be configured via the webConfig tool.
8.2 Configuring the switching inputs/outputs
Ä Set the configuration of the switching inputs/outputs via the webConfig tool or via connection hood
MS307 or MK307.
ð Setting via the webConfig tool: CONFIGURATION > DEVICE (see chapter 9.3.4 "CONFIGURATION
function")
ð Setting via connection hood MS 307/MK 307 (see chapter 8.6 "Configuration via the switches of the
connection hood")
NOTICE
Devices with connection hood KB307 can only be configured via the webConfig tool.
8.3 Configuring the resolution for the position value
Ä Set the parameters for the resolution during position measurement via the webConfig tool or via con-
nection hood MS307 or MK307.
ð Setting via the webConfig tool: CONFIGURATION > OUTPUT (see chapter 9.3.4 "CONFIGURATION
function")
ð Setting via connection hood MS 307/MK 307 (see chapter 8.6 "Configuration via the switches of the
connection hood")
NOTICE
Devices with connection hood KB307 can only be configured via the webConfig tool.
8.4 Configuring speed monitoring with switching output
Ä Set the parameters for speed monitoring via the webConfig tool or via connection hood MS307 or
MK307.
ð Setting via the webConfig tool:
ð Switching output function: CONFIGURATION > DEVICE > Switching inputs/outputs (see chapter
9.3.4 "CONFIGURATION function")
ð Speed limit values: CONFIGURATION > DATA PROCESSING > Speed > Monitoring (see chapter
9.3.4 "CONFIGURATION function")
ð Setting via connection hood MS 397/MK 397 (see chapter 8.6 "Configuration via the switches of the
connection hood")
NOTICE
Devices with connection hood KB307 can only be configured via the webConfig tool.
