Technical data
Leuze electronic GmbH + Co. KG BPS 307i 77
Tab.13.2: Measurement data
Reproducibility (1sigma) ±0.05mm
Output time 0.05ms…2ms (configurable)
Default: 2ms
Response time 8ms (adjustable, factory setting 8ms)
Basis for contouring error calculation 4ms
Measurement range 0…10,000,000mm
Resolution 0.1mm (adjustable, factory setting 0.1mm)
Max. traverse rate 10m/s
Tab.13.3: Operating and display elements
Display (optional – only in device mod-
els with "D")
Monochromatic graphical display, 128x32 pixels,
With background lighting
Keyboard (optional – only in device
models with "D")
Two buttons
LEDs Two LEDs for power (PWR) and bus state (BUS), two-colored
(red/green)
Tab.13.4: Mechanical data
Housing Diecast aluminum
Connection technology • BPS with MS307: M12 connectors
• BPS with MK307: Terminal blocks with spring-cage termi-
nals (5-pin)
• BPS with KB307: cable connection
Degree of protection IP65
Weight Approx. 580g (without connection hood)
Dimensions of the BPS 307i without
connection hood
(HxWxD) 108.7mmx100.0mmx48.3mm
Dimensions (with MS307 connection
hood)
(HxWxD) 108.7mmx100.0mmx48.3mm
Dimensions (with MK307 connection
hood)
(HxWxD) 147.4mmx100.0mmx48.3mm
Dimensions (with KB307 connection
hood)
(HxWxD) 108.7mmx100.0mmx48.3mm
Dimensions of MS307 connection hood (HxWxD) 64.0mmx43.5mmx33.5mm
Dimensions of MK307 connection hood (HxWxD) 64.0mmx43.5mmx83.5mm
Dimensions of KB307 connection hood (HxWxD) 64.0mmx43.5mmx18.1mm
Tab.13.5: Environmental data
Air humidity Max. 90% rel. humidity, non-condensing
Vibration IEC60068-2-6, testFc
Shock
Continuous shock
IEC 60068-2-27, test Ea
Electromagnetic compatibility IEC61000-6-3
IEC61000-6-2 (contains IEC61000-4-2,-3,-4,-5,-6)
