Lexmark E260 Service Manual

2-58 Lexmark™ E260, E260d, E260dn
4513-200, -220, -230
Media picks but stops halfway through the printer
Media never picks
Media occasionally mispicks or picks multiple sheets at once
FRU Action
Input/duplex sensors
(under print cartridge assembly)
Input sensor (manual)
Make sure the input sensors are working properly.
Check for a broken or stuck flag on the input sensors. Clear anything that
keeps the flags from rotating freely.
Make sure the cables are seated on the controller board at J27 (input/duplex
sensor) and J23 (manual input).
Check for +5 V dc on pin 2 and 5 at J27 (input/duplex sensors) and pin 2 at
J23 (Input sensor). Voltages on pins 1 and 4 at J27 pin 1 at &23 should
charge as the flags intersect with the sensor.
• If correct, then replace the input paper feed sensor.
• If these voltages are not correct, then replace the controller board.
• Check the pick tires. Clean or replace as necessary.
FRU Action
Paper feed (pick tires) tray 1
Paper feed (pick tires) tray 2
Media drive ASM
Media feed clutch ASM
Manual feed clutch ASM
P/U and manual feed solenoid
ACM drive shaft
Open the left cover, and verify that the solenoids and clutches are functioning
when an attempt is made to feed the media.
Make sure the rubber tires on the ACM are installed and clean.
Replace the tires, ACM drive, clutch assemblies, solenoids, or drive shaft as
necessary.
FRU Action
Tray 1
Tray 2 (option)
Check tray for media catch points.
If the sheet being fed stops momentarily, then the ACM applies additional vertical force,
causing additional sheets to feed.
Do not mix media types in one tray.
Paper pick tires
(Tray 1 or tray 2)
Check the tires in the ACM assembly for signs of wear or damage.
Replace the tires as necessary.
ACM clutch
Manual feed clutch
Media feed clutch ASM
(tray 1 only)
Manual feed clutch
solenoid
Open left cover, and observe the solenoid and clutch actions at the ACM and manual
feed shafts as a print job is attempted.
Replace the faulty part.
Controller board
P/U and manual feed
solenoid ASM.
Disconnect the solenoid cable at J26 on the controller board and measure the resistance
across cable pins 1 and 2.
• The resistance should be approximately 70 ohms.
• If it is not, then replace the solenoid.
• If the resistance is approximately 70 ohms, then check the controller board. Pin 1 at
J26 should be +24 V dc. See “Controller board service check” on page 2-52 for
more information.
Replace controller board as necessary.

Lexmark E260 Specifications

General

Color	No
Duplex printing	-
Maximum resolution	1200 x 1200 DPI
Time to first page (black, normal)	6.5 s
Print margins (top, bottom, right, left)	4 mm
Print speed (black, normal quality, A4/US Letter)	33 ppm
Maximum internal memory	160 MB
Sound pressure level (printing)	53 dB
Sound pressure level (quiet mode)	48 dB
Total input capacity	250 sheets
Maximum input capacity	800 sheets
Envelopes sizes	7 3/4, 9, 10, B5, C5, DL
Maximum print size	216 x 297 mm
Paper tray media types	Envelopes, Labels, Plain paper, Transparencies
Paper tray media weight	60 - 90 g/m²
Non-ISO print media sizes	Executive (184 x 267mm), Folio (media size), Letter (media size), Statement (140 x 216mm)
ISO A-series sizes (A0...A9)	A4, A5, A6
JIS B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A4
Memory upgrade	Yes GB
Mac compatibility	Yes
Standard input trays	2
Standard media sizes	10 envelop 7 3/4 envelop 9 envelop A4 A5 B5 envelop C5 envelop DL envelop A6 Executive Folio JIS-B5 Legal Letter Statement Universeel aan te passen afmetingen Oficio
Pallet weight (imperial)	656 lbs
Compatible operating systems	Linpus Linux Desktop 9.2, 9.3 Red Hat Enterprise Linux WS 3.0, 4.0, 5.0 SUSE Linux Enterprise Server 8.0, 9.0, 10, 11 SUSE Linux Enterprise Desktop 10 openSUSE 10.2, 10.3, 11.0, 11.1 Linspire Linux 6.0 Debian GNU/Linux 4.0 Red Flag Linux Desktop 5.0, 6.0 Ubuntu 7.10 Ubuntu 8.04 LTS SUSE Linux Enterprise Desktop 11 Debian GNU/Linux 5.0 Ubuntu 8.10, 9.04 Microsoft Windows 2000 Microsoft Windows XP Microsoft Windows Server 2003 Microsoft Windows XP x64 Microsoft Windows Server 2003 x64 Microsoft Windows Vista Microsoft Windows Vista x64 Microsoft Windows Server 2008 Microsoft Windows Server 2008 x64 Microsoft Windows 7 Apple Mac OS X Apple Mac OS 9.2
Duty cycle letter size (maximum)	2500 pages per month
Copy speed (black, normal quality, A4)	33 cpm
Maximum duty cycle	50000 pages per month
Operating temperature (T-T)	16 - 32 °C
Operating relative humidity (H-H)	8 - 80 %
Certification	FCC B, UL 60950-1, U.S. FDA, IEC 320-1, CSA, ICES Class B, CE Class B, CB IEC 60950-1, IEC 60825-1, GS (TÜV), SEMKO, UL AR, CS, TÜV Rh, N Mark, ACA C-tick B, CCC B, BSMI B, MIC, EK Mark, PSB
Power consumption (standby)	12 W
Power consumption (printing)	470 W
Power consumption (PowerSave)	11 W
Pallet weight	298000 g
Quantity per pallet	18 pc(s)
Package weight	15700 g
Standard interfaces	Parallel, USB 2.0
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.

Weight and Dimensions

Dimensions (WxDxH)	406 x 370 x 260 mm
Pallet dimensions (W x D x H)	1420 x 870 x 1219 mm
