LG multi V PLUS Service Manual

118 Indoor Unit
Dimiensional Drawings
4. Dimiensional Drawings
LRNV076SRA(L)0/LRNN076SRA(L)0/LRNV072SRA(L)0/LRNN072SRA(L)0
LRNV096SRA(L)0/LRNN096SRA(L)0/LRNV092SRA(L)0/LRNN092SRA(L)0
LRNV126SRA(L)0/LRNN126SRA(L)0/LRNV122SRA(L)0/LRNN122SRA(L)0
LRNV186STA(L)0/LRNN186STA(L)0/LRNV182STA(L)0/LRNN182STA(L)0
Installation plate
D
H
W
More than 5cm
More than
5cm
More than 2.3m
More than
5cm
4020400
0
D
0
BCA
210105
ST
(18k)
SR
(7k/9k/12k)
Distance(mm)
CHASSIS
(Grade)
Installation plate
Ø70mm
Left rear piping Right rear piping
C
D
B
A
Ø70mm
W
900
1090
H
285
314
D
156
172
Model
LRNV076SRA(L)0/LRNN076SRA(L)0
LRNV072SRA(L)0/LRNN072SRA(L)0
LRNV096SRA(L)0/LRNN096SRA(L)0
LRNV092SRA(L)0/LRNN092SRA(L)0
LRNV126SRA(L)0/LRNN126SRA(L)0
LRNV122SRA(L)0/LRNN122SRA(L)0
LRNV186STA(L)0/LRNN186STA(L)0
LRNV182STA(L)0/LRNN182STA(L)0
(unit:mm)
