Service Manual 299
Resistance-Temperature Table
Resistance-Temperature Table
T Rmin Rcent Rmax DR DT(°C)
-30 79.62 86.91 94.78 9.05% 1.42
-29 75.02 81.79 89.08 8.92% 1.41
-28 70.71 77.00 83.76 8.79% 1.40
-27 66.67 72.51 78.79 8.66% 1.39
-26 62.89 68.31 74.14 8.53% 1.38
-25 59.34 64.38 69.79 8.40% 1.37
-24 56.00 60.69 65.71 8.27% 1.36
-23 52.88 57.24 61.90 8.15% 1.35
-22 49.94 54.00 58.33 8.02% 1.33
-21 47.19 50.96 54.98 7.90% 1.32
-20 44.60 48.11 51.85 7.77% 1.31
-19 42.17 45.43 48.91 7.65% 1.30
-18 39.88 42.92 46.15 7.53% 1.29
-17 37.73 40.56 43.57 7.40% 1.28
-16 35.71 38.35 41.14 7.28% 1.26
-15 33.81 36.26 38.86 7.16% 1.25
-14 32.02 34.30 36.72 7.04% 1.24
-13 30.33 32.46 34.71 6.93% 1.23
-12 28.74 30.73 32.82 6.81% 1.22
-11 27.25 29.10 31.04 6.69% 1.20
-10 25.84 27.56 29.37 6.58% 1.19
-9 24.51 26.11 27.80 6.46% 1.18
-8 23.25 24.75 26.32 6.35% 1.16
-7 22.07 23.47 24.93 6.23% 1.15
-6 20.95 22.26 23.62 6.12% 1.14
-5 19.90 21.12 22.39 6.01% 1.13
-4 18.91 20.04 21.22 5.90% 1.11
-3 17.97 19.02 20.13 5.79% 1.10
-2 17.08 18.07 19.09 5.68% 1.09
-1 16.24 17.16 18.12 5.57% 1.07
0 15.45 16.31 17.20 5.46% 1.06
1 14.70 15.50 16.33 5.36% 1.04
2 13.99 14.74 15.51 5.25% 1.03
3 13.32 14.02 14.74 5.15% 1.02
4 12.68 13.33 14.01 5.04% 1.00
5 12.08 12.69 13.32 4.94% 0.99
6 11.51 12.08 12.66 4.83% 0.97
7 10.97 11.50 12.05 4.73% 0.96
8 10.46 10.96 11.46 4.63% 0.95
9 9.978 10.44 10.91 4.53% 0.93
10 9.518 9.949 10.39 4.43% 0.92
T Rmin Rcent Rmax DR DT(°C)
51 1.649 1.736 1.826 5.20% 1.39
52 1.587 1.672 1.760 5.28% 1.42
53 1.527 1.610 1.697 5.36% 1.45
54 1.470 1.552 1.636 5.44% 1.48
55 1.416 1.495 1.578 5.52% 1.51
56 1.364 1.441 1.522 5.59% 1.54
57 1.314 1.389 1.468 5.67% 1.57
58 1.266 1.340 1.417 5.75% 1.60
59 1.220 1.292 1.367 5.83% 1.63
60 1.176 1.246 1.320 5.90% 1.66
61 1.134 1.203 1.274 5.98% 1.69
62 1.093 1.161 1.231 6.05% 1.72
63 1.054 1.120 1.189 6.13% 1.76
64 1.017 1.081 1.148 6.20% 1.79
65 0.9815 1.044 1.110 6.28% 1.82
66 0.9472 1.008 1.072 6.35% 1.85
67 0.9143 0.9739 1.037 6.43% 1.88
68 0.8827 0.9409 1.002 6.50% 1.91
69 0.8523 0.9092 0.9689 6.57% 1.95
70 0.8232 0.8787 0.9370 6.64% 1.98
71 0.7951 0.8493 0.9064 6.72% 2.01
72 0.7682 0.8211 0.8768 6.79% 2.04
73 0.7423 0.7940 0.8484 6.86% 2.08
74 0.7174 0.7678 0.8211 6.93% 2.11
75 0.6935 0.7427 0.7947 7.00% 2.14
76 0.6704 0.7185 0.7693 7.07% 2.18
77 0.6483 0.6952 0.7449 7.15% 2.21
78 0.6270 0.6728 0.7214 7.22% 2.25
79 0.6064 0.6512 0.6987 7.29% 2.28
80 0.5867 0.6304 0.6768 7.36% 2.31
81 0.5677 0.6104 0.6557 7.42% 2.35
82 0.5494 0.5911 0.6353 7.49% 2.38
83 0.5317 0.5724 0.6157 7.56% 2.42
84 0.5147 0.5545 0.5968 7.63% 2.45
85 0.4983 0.5372 0.5786 7.70% 2.49
86 0.4826 0.5205 0.5610 7.77% 2.52
87 0.4674 0.5044 0.5440 7.84% 2.56
88 0.4527 0.4889 0.5275 7.90% 2.59
89 0.4386 0.4739 0.5117 7.97% 2.63
90 0.4249 0.4595 0.4964 8.04% 2.67
T Rmin Rcent Rmax DR DT(°C)
11 9.083 9.484 9.895 4.33% 0.90
12 8.669 9.044 9.427 4.23% 0.89
13 8.277 8.627 8.983 4.13% 0.87
14 7.905 8.231 8.563 4.03% 0.86
15 7.551 7.856 8.165 3.93% 0.84
16 7.216 7.500 7.787 3.84% 0.83
17 6.897 7.161 7.430 3.74% 0.81
18 6.594 6.841 7.090 3.65% 0.80
19 6.306 6.536 6.768 3.55% 0.78
20 6.032 6.246 6.462 3.46% 0.76
21 5.772 5.971 6.172 3.37% 0.75
22 5.524 5.710 5.897 3.27% 0.73
23 5.288 5.461 5.635 3.18% 0.72
24 5.064 5.225 5.386 3.09% 0.70
25 4.850 5.000 5.150 3.00% 0.68
26 4.638 4.786 4.934 3.09% 0.71
27 4.437 4.583 4.728 3.18% 0.73
28 4.246 4.389 4.532 3.27% 0.76
29 4.064 4.204 4.345 3.36% 0.79
30 3.891 4.028 4.167 3.45% 0.81
31 3.726 3.861 3.997 3.53% 0.84
32 3.569 3.701 3.835 3.62% 0.86
33 3.419 3.549 3.681 3.71% 0.89
34 3.277 3.404 3.534 3.79% 0.92
35 3.141 3.266 3.393 3.88% 0.94
36 3.012 3.134 3.258 3.97% 0.97
37 2.888 3.008 3.130 4.05% 1.00
38 2.771 2.888 3.008 4.14% 1.02
39 2.659 2.773 2.890 4.22% 1.05
40 2.552 2.664 2.779 4.31% 1.08
41 2.450 2.559 2.672 4.39% 1.10
42 2.352 2.459 2.569 4.47% 1.13
43 2.259 2.364 2.472 4.55% 1.16
44 2.170 2.273 2.378 4.64% 1.19
45 2.085 2.185 2.289 4.72% 1.22
46 2.004 2.102 2.203 4.80% 1.25
47 1.926 2.022 2.121 4.88% 1.27
48 1.852 1.946 2.042 4.96% 1.30
49 1.781 1.873 1.967 5.04% 1.33
50 1.713 1.803 1.895 5.12% 1.36
T Rmin Rcent Rmax DR DT(°C)
91 0.4118 0.4455 0.4816 8.10% 2.70
92 0.3991 0.4321 0.4674 8.17% 2.74
93 0.3868 0.4191 0.4536 8.24% 2.77
94 0.3750 0.4065 0.4402 8.30% 2.81
95 0.3636 0.3944 0.4274 8.37% 2.85
96 0.3526 0.3826 0.4149 8.43% 2.88
97 0.3419 0.3713 0.4029 8.50% 2.92
98 0.3317 0.3604 0.3912 8.56% 2.96
99 0.3217 0.3498 0.3800 8.63% 3.00
100 0.3121 0.3396 0.3691 8.69% 3.03
101 0.3029 0.3297 0.3586 8.76% 3.07
102 0.2939 0.3201 0.3484 8.82% 3.11
103 0.2853 0.3109 0.3385 8.88% 3.15
104 0.2769 0.3019 0.3290 8.95% 3.19
105 0.2688 0.2933 0.3197 9.01% 3.22
106 0.2610 0.2849 0.3108 9.07% 3.26
107 0.2534 0.2768 0.3021 9.14% 3.30
108 0.2461 0.2690 0.2937 9.20% 3.34
109 0.2390 0.2614 0.2856 9.26% 3.38
110 0.2321 0.2540 0.2777 9.33% 3.42
Thermistor: LNTA502HF
Note: T : Temperature(°C)
Rmin : Minimum value of Resistance
Rcent : Central value of Resistance
Rmax : Maximum value of Resistance
DR : Deviation Ratio
DT : Deviation Temperature
