300 Trouble Shooting Guide
Resistance-Temperature Table
T Rmin Rcent Rmax DR DT(°C)
-30 159.2 173.8 189.6 9.05% 1.42
-29 150.0 163.6 178.2 8.92% 1.41
-28 141.4 154.0 167.5 8.79% 1.40
-27 133.3 145.0 157.6 8.66% 1.39
-26 125.8 136.6 148.3 8.53% 1.38
-25 118.7 128.8 139.6 8.40% 1.37
-24 112.0 121.4 131.4 8.27% 1.36
-23 105.8 114.5 123.8 8.15% 1.35
-22 99.89 108.0 116.7 8.02% 1.33
-21 94.38 101.9 110.0 7.90% 1.32
-20 89.20 96.22 103.7 7.77% 1.31
-19 84.34 90.87 97.82 7.65% 1.30
-18 79.76 85.84 92.30 7.53% 1.29
-17 75.46 81.12 87.13 7.40% 1.28
-16 71.42 76.69 82.28 7.28% 1.26
-15 67.61 72.52 77.72 7.16% 1.25
-14 64.03 68.61 73.44 7.04% 1.24
-13 60.66 64.92 69.42 6.93% 1.23
-12 57.48 61.45 65.64 6.81% 1.22
-11 54.49 58.19 62.09 6.69% 1.20
-10 51.67 55.12 58.74 6.58% 1.19
-9 49.01 52.23 55.60 6.46% 1.18
-8 46.51 49.50 52.65 6.35% 1.16
-7 44.14 46.94 49.86 6.23% 1.15
-6 41.91 44.52 47.24 6.12% 1.14
-5 39.80 42.23 44.77 6.01% 1.13
-4 37.81 40.08 42.45 5.90% 1.11
-3 35.94 38.05 40.25 5.79% 1.10
-2 34.16 36.13 38.19 5.68% 1.09
-1 32.48 34.32 36.24 5.57% 1.07
0 30.90 32.62 34.40 5.46% 1.06
1 29.40 31.00 32.66 5.36% 1.04
2 27.98 29.48 31.02 5.25% 1.03
3 26.64 28.03 29.48 5.15% 1.02
4 25.37 26.67 28.01 5.04% 1.00
5 24.16 25.38 26.63 4.94% 0.99
6 23.03 24.16 25.33 4.83% 0.97
7 21.95 23.01 24.09 4.73% 0.96
8 20.92 21.91 22.93 4.63% 0.95
9 19.96 20.88 21.82 4.53% 0.93
10 19.04 19.90 20.78 4.43% 0.92
T Rmin Rcent Rmax DR DT(°C)
51 3.297 3.472 3.652 5.20% 1.39
52 3.173 3.344 3.520 5.28% 1.42
53 3.054 3.221 3.394 5.36% 1.45
54 2.940 3.103 3.272 5.44% 1.48
55 2.832 2.990 3.155 5.52% 1.51
56 2.727 2.882 3.044 5.59% 1.54
57 2.627 2.779 2.936 5.67% 1.57
58 2.532 2.680 2.834 5.75% 1.60
59 2.440 2.584 2.735 5.83% 1.63
60 2.352 2.493 2.640 5.90% 1.66
61 2.267 2.405 2.549 5.98% 1.69
62 2.187 2.321 2.462 6.05% 1.72
63 2.109 2.240 2.378 6.13% 1.76
64 2.035 2.163 2.297 6.20% 1.79
65 1.963 2.088 2.219 6.28% 1.82
66 1.894 2.017 2.145 6.35% 1.85
67 1.829 1.948 2.073 6.43% 1.88
68 1.765 1.882 2.004 6.50% 1.91
69 1.705 1.818 1.938 6.57% 1.95
70 1.646 1.757 1.874 6.64% 1.98
71 1.590 1.699 1.813 6.72% 2.01
72 1.536 1.642 1.754 6.79% 2.04
73 1.485 1.588 1.697 6.86% 2.08
74 1.435 1.536 1.642 6.93% 2.11
75 1.387 1.485 1.589 7.00% 2.14
76 1.341 1.437 1.539 7.07% 2.18
77 1.297 1.390 1.490 7.15% 2.21
78 1.254 1.346 1.443 7.22% 2.25
79 1.213 1.302 1.397 7.29% 2.28
80 1.173 1.261 1.354 7.36% 2.31
81 1.135 1.221 1.311 7.42% 2.35
82 1.099 1.182 1.271 7.49% 2.38
83 1.063 1.145 1.231 7.56% 2.42
84 1.029 1.109 1.194 7.63% 2.45
85 0.9967 1.074 1.157 7.70% 2.49
86 0.9651 1.041 1.122 7.77% 2.52
87 0.9347 1.009 1.088 7.84% 2.56
88 0.9054 0.9778 1.055 7.90% 2.59
89 0.8771 0.9479 1.023 7.97% 2.63
90 0.8498 0.9190 0.9928 8.04% 2.67
T Rmin Rcent Rmax DR DT(°C)
11 18.17 18.97 19.79 4.33% 0.90
12 17.34 18.09 18.85 4.23% 0.89
13 16.55 17.25 17.97 4.13% 0.87
14 15.81 16.46 17.13 4.03% 0.86
15 15.10 15.71 16.33 3.93% 0.84
16 14.43 15.00 15.57 3.84% 0.83
17 13.79 14.32 14.86 3.74% 0.81
18 13.19 13.68 14.18 3.65% 0.80
19 12.61 13.07 13.54 3.55% 0.78
20 12.06 12.49 12.92 3.46% 0.76
21 11.54 11.94 12.34 3.37% 0.75
22 11.05 11.42 11.79 3.27% 0.73
23 10.58 10.92 11.27 3.18% 0.72
24 10.13 10.45 10.77 3.09% 0.70
25 9.700 10.00 10.30 3.00% 0.68
26 9.277 9.572 9.868 3.09% 0.71
27 8.875 9.165 9.456 3.18% 0.73
28 8.492 8.777 9.064 3.27% 0.76
29 8.128 8.408 8.691 3.36% 0.79
30 7.781 8.057 8.335 3.45% 0.81
31 7.452 7.722 7.995 3.53% 0.84
32 7.138 7.403 7.671 3.62% 0.86
33 6.839 7.099 7.362 3.71% 0.89
34 6.554 6.809 7.067 3.79% 0.92
35 6.282 6.532 6.786 3.88% 0.94
36 6.024 6.268 6.517 3.97% 0.97
37 5.777 6.016 6.260 4.05% 1.00
38 5.542 5.776 6.015 4.14% 1.02
39 5.317 5.547 5.781 4.22% 1.05
40 5.103 5.328 5.557 4.31% 1.08
41 4.899 5.119 5.343 4.39% 1.10
42 4.704 4.919 5.139 4.47% 1.13
43 4.518 4.728 4.943 4.55% 1.16
44 4.340 4.545 4.756 4.64% 1.19
45 4.170 4.371 4.577 4.72% 1.22
46 4.008 4.204 4.406 4.80% 1.25
47 3.853 4.044 4.242 4.88% 1.27
48 3.704 3.892 4.085 4.96% 1.30
49 3.563 3.746 3.934 5.04% 1.33
50 3.427 3.606 3.790 5.12% 1.36
T Rmin Rcent Rmax DR DT(°C)
91 0.8235 0.8911 0.9633 8.10% 2.70
92 0.7981 0.8641 0.9347 8.17% 2.74
93 0.7736 0.8381 0.9071 8.24% 2.77
94 0.7500 0.8130 0.8805 8.30% 2.81
95 0.7272 0.7887 0.8547 8.37% 2.85
96 0.7051 0.7653 0.8298 8.43% 2.88
97 0.6839 0.7426 0.8058 8.50% 2.92
98 0.6633 0.7208 0.7825 8.56% 2.96
99 0.6435 0.6996 0.7600 8.63% 3.00
100 0.6243 0.6792 0.7382 8.69% 3.03
101 0.6057 0.6594 0.7171 8.76% 3.07
102 0.5878 0.6403 0.6967 8.82% 3.11
103 0.5705 0.6218 0.6770 8.88% 3.15
104 0.5538 0.6039 0.6579 8.95% 3.19
105 0.5376 0.5866 0.6394 9.01% 3.22
106 0.5219 0.5698 0.6215 9.07% 3.26
107 0.5068 0.5536 0.6042 9.14% 3.30
108 0.4921 0.5379 0.5874 9.20% 3.34
109 0.4780 0.5227 0.5711 9.26% 3.38
110 0.4643 0.5080 0.5554 9.33% 3.42
Thermistor: 103HF
Note: T : Temperature(°C)
Rmin : Minimum value of Resistance
Rcent : Central value of Resistance
Rmax : Maximum value of Resistance
DR : Deviation Ratio
DT : Deviation Temperature
