LG multi V PLUS Service Manual

14
3. Combination of Outdoor Units
Combination of Outdoor Units
■ Up to a maximum 40HP are realized by combining 8, 10, 12, 14 and 16HP
■ * :3Ø, 380V, 60Hz
System Capacity Number of Units Module
50Hz(60Hz)
56810121416
5HP 1(1) 1
6HP 1(1) 1
8HP 1(1) 1
10HP 1(1) 1
12HP 1(1) 1
14HP 1(1) 1
16HP 2(2) 2
18HP 2(2) 1 1
20HP 2(2) 2
22HP 2(2) 1 1
24HP 2(2) 2
26HP 3(2) 2 1 *(1) *(1)
28HP 3(3) 1 2
30HP 3(3) 3
32HP 3(3) 2 1
34HP 3(3) 2 1
36HP 3(3) 3
38HP 3(3) 2 1
40HP 3(3) 2 1
