242 Outdoor Unit
Wiring Diagrams
Inverter Board
CN10, CN11, CN12, CN13 IPM
CN1 POWER
CN4 H/P, M
CN2 DC LINK
CN6 SIGNAL
CN5 PHASE
CN3 WRITE
