136 Indoor Unit
Dimensional Drawings
5. Dimensional Drawings
LRNV076SU*0/LRNN076SU*0/LRNV072SU*0/LRNN072SU*0
LRNV096SU*0/LRNN096SU*0/LRNV092SU*0/LRNN092SU*0
LRNV126SU*0/LRNN126SU*0/LRNV122SU*0/LRNN122SU*0
LRNV186S3*0/LRNN186S3*0/LRNV182S3*0/LRNN182S3*0
LRNV246S3*0/LRNN246S3*0/LRNV242S3*0/LRNN242S3*0
More than 10cm
More than 2.3m
More than 5cm
More than
5cm
Installation plate
Pipe See Note
Drain Hose
D
H
W
45 45
4-R7
R208
153
78
52
1030
1030
494
361
970
153
5313
(unit : mm)
W
1030
H
290
D
153
Model
LRNV076SU*0/LRNN076SU*0/LRNV072SU*0/LRNN072SU*0
LRNV096SU*0/LRNN096SU*0/LRNV092SU*0/LRNN092SU*0
LRNV126SU*0/LRNN126SU*0/LRNV122SU*0/LRNN122SU*0
LRNV186S3*0/LRNN186S3*0/LRNV182S3*0/LRNN182S3*0
LRNV246S3*0/LRNN246S3*0/LRNV242S3*0/LRNN242S3*0
1170 315 170
