Service Manual 49
Dimensional Drawings
4. Dimensional Drawings
LRNV126TEA(C)0/LRNN126TEA(C)0/LRNV12TEA(C)0/LRNN122TEA(C)0
LRNV186TEA(C)0/LRNN186TEA(C)0/LRNV182TEA(C)0/LRNN182TEA(C)0
CLOSE OPEN OPEN CLOSE
269
670
30
570
269
190.5
160
52
90
90
120.4
30
521
670
570
450
40
110 110
670
670
4
1
3
2
5
6
Unit:mm
570 Unit size
570 Unit size
450 (Hanging bolt)
7575
600 (Ceiling opening)
600 (Ceiling opening)
521(Hanging bolt)
39.5
39.5
(unit : mm)
Number Name Descripition
1 Liquid pipe connection
Unit Size(12k):Ø6.35, (18k):Ø9.52
2 Gas pipe connection
Unit Size(12k):
Ø
12.7, (18k):
Ø
15.88
3 Drain pipe connection
4 Power supply connection
5 Air discharge grill
6 Air suction grill
