LG multi V PLUS Service Manual

Service Manual 183
Specifications
380V, Cooling Only(50Hz)
Notes:
1. Capacities are based on the following conditions:
Cooling * Indoor temp. 27°C[80.6°F]DB/ 19°C[66.2°F]WB
* Outdoor temp. 35°C[95°F]DB/ 24°C[75.2°F]WB
* Interconnecting Piping Length 7.5m
* Level Difference of Zero
2. Capacities are net capacities
3. Due to our policy of innovation some specifications may be changed without notification
4. L.E.V.:Linear Expansion Valve
Conversion Formula
Kcal/h= kW x 860
Btu/h = kW x 3412
cfm = m
3
/min x 35.3
HP
Model Name Combination Unit
Independent Unit
Capacity Cooling W
kcal/h
Btu/h
Heating W
kcal/h
Btu/h
Input Cooling kW
Heating kW
Casing Color
Heat Exchanger
Compressor Type
Maker
Piston Displacement cm
2
/rev
Number of Revolution r.p.m
Motor Output x Number W
Starting Method
Oil Type
Oil Charge CC
Fan Type
Motor Output x Number W
Air Flow Rate(High) cmm
cfm
Drive
Discharge Side / Top
Pipe Connctions Liquid Pipes mm(inch)
Gas Pipes mm(inch)
Dimensions (W*H*D) mm
inch
Net Weight kg
lbs
Power Supply Cable mm
2
Transmission Cable mm
2
Refigerant Refigerant name
Control
Power Supply Ø / V / Hz
20 22 24 26
LRUV2008TS0 LRUV2208TS0 LRUV2408TS0 LRUV2608TR0
LRUV1008TS0 LRUV1208TS0 LRUV1208TS0 LRUV1008TR0
LRUC1008TS0 LRUC1008TS0 LRUC1208TS0 LRUC808TR0
LRUC808TR0
56,000 61,600 67,200 72,800
48,200 53,000 57,800 62,600
191,100 210,200 229,300 248,400
----
----
----
17.8 20.7 23.6 22.9
----
WARM GRAY WARM GRAY WARM GRAY WARM GRAY
Louver Fin Louver Fin Louver Fin Louver Fin
Scroll Scroll Scroll Scroll
LG LG LG LG
(77.87+110)+(110+110) (77.87+110)+(110+110) (77.87+110)+(110+110) (77.87+110)+(110+110)x2
(3472, 2900)+(2900, 2900) (3472, 2900)+(2900, 2900) (3472, 2900)+(2900, 2900) (3472, 2900)+(2900, 2900)x2
(4309+4900)+(4900+4900) (4309+4900)+(4900+4900) (4309+4900)+(4900+4900) (4309+4900)+(4900+4900)x2
Direct on Line Direct on Line Direct on Line Direct on Line
SUNISO 4GSI SUNISO 4GSI SUNISO 4GSI SUNISO 4GSI
2325 ± 10, (2325 ± 10)x3 2325 ± 10, (2325 ± 10)x3 2325 ± 10, (2325 ± 10)x3 2325 ± 10, (2325 ± 10)x5
Propeller Fan Propeller Fan Propeller Fan Propeller Fan
291x2+271x2 291x2+271x2 291x2+271x2 291x2+271x4
90x4 90x4 90x4 90x6
3177x4 3177x4 3177x4 3177x6
Inverter Inverter Inverter Inverter
Top Top Top Top
Ø19.05(3/4) Ø19.05(3/4) Ø19.05(3/4) Ø22.2(7/8)
Ø38.1(1 1/2) Ø38.1(1 1/2) Ø38.1(1 1/2) Ø44.5(1 3/4)
(1280 * 1555 * 730)x2 (1280 * 1555 * 730)x2 (1280 * 1555 * 730)x2 (1280 * 1555 * 730)x3
(50.4 * 61.2 * 28.7)x2 (50.4 * 61.2 * 28.7)x2 (50.4 * 61.2 * 28.7)x2 (50.4 * 61.2 * 28.7)x3
300x2 300x2 300x2 300x3
661.4x2 661.4x2 661.4x2 661.4x3
CV 14X5C CV 14X5C CV 14X5C CV 14X5C
CVV-SB 1.25X2C CVV-SB 1.25X2C CVV-SB 1.25X2C CVV-SB 1.25X2C
R22 R22 R22 R22
L.E.V L.E.V L.E.V L.E.V
3 / 380 ~ 415 / 50 3 / 380 ~ 415 / 50 3 / 380 ~ 415 / 50 3 / 380 ~ 415 / 50
