Specifications
380V, Heat Pump(50Hz)
Notes:
1. Capacities are based on the following conditions:
Cooling * Indoor temp. 27°C[80.6°F]DB/ 19°C[66.2°F]WB
* Outdoor temp. 35°C[95°F]DB/ 24°C[75.2°F]WB
* Interconnecting Piping Length 7.5m
* Level Difference of Zero
Heating * Indoor temp. 20°C[68°F]DB/ 15°C[59°F]WB
* Outdoor temp. 7°C[44.6°F]DB/ 6°C[42.8°F]WB
* Interconnecting Piping Length 7.5m
* Level Difference of Zero
2. Capacities are net capacities
3. Due to our policy of innovation some specifications may be changed without notification
4. L.E.V.:Linear Expansion Valve
Conversion Formula
Kcal/h= kW x 860
Btu/h = kW x 3412
cfm = m
3
/min x 35.3
HP
Model Name Combination Unit
Independent Unit
Capacity Cooling W
kcal/h
Btu/h
Heating W
kcal/h
Btu/h
Input Cooling kW
Heating kW
Casing Color
Heat Exchanger
Compressor Type
Maker
Piston Displacement cm
2
/rev
Number of Revolution r.p.m
Motor Output x Number W
Starting Method
Oil Type
Oil Charge CC
Fan Type
Motor Output x Number W
Air Flow Rate(High) cmm
cfm
Drive
Discharge Side / Top
Pipe Connctions Liquid Pipes mm(inch)
Gas Pipes mm(inch)
Dimensions (W*H*D) mm
inch
Net Weight kg
lbs
Power Supply Cable mm
2
Transmission Cable mm
2
Refigerant Refigerant name
Control
Power Supply Ø / V / Hz
28 30 32 34
LRUN2808TR0 LRUN3008TR0 LRUN3208TR0 LRUN3408TR0
LRUN808TR0 LRUN1008TR0 LRUN1208TR0 LRUN1408TR0
LRUH1008TR0 LRUH1008TR0 LRUH1008TR0 LRUH1008TR0
LRUH1008TR0 LRUH1008TR0 LRUH1008TR0 LRUH1008TR0
78,400 84,000 89,600 95,200
67,400 72,200 77,100 81,900
267,500 286,600 305,700 324,800
88,200 94,500 100,800 107,100
75,900 81,300 86,700 92,100
301,000 322,500 343,900 365,400
24.8 26.7 29.6 31.7
24 25.8 28.2 30.2
WARM GRAY WARM GRAY WARM GRAY WARM GRAY
Louver Fin Louver Fin Louver Fin Louver Fin
Scroll Scroll Scroll Scroll
LG LG LG LG
77.87+110x5 77.87+110x5 77.87+110x5 77.87+110x5
(3472, 2900)+(2900, 2900)x2 (3472, 2900)+(2900, 2900)x2 (3472, 2900)+(2900, 2900)x2 (3472, 2900)+(2900, 2900)x2
(4309+4900)+(4900+4900)x2 (4309+4900)+(4900+4900)x2 (4309+4900)+(4900+4900)x2 (4309+4900)+(4900+4900)x2
Direct on Line Direct on Line Direct on Line Direct on Line
SUNISO 4GSI SUNISO 4GSI SUNISO 4GSI SUNISO 4GSI
2325 ± 10, (2325 ± 10)x5 2325 ± 10, (2325 ± 10)x5 2325 ± 10, (2325 ± 10)x5 2325 ± 10, (2325 ± 10)x5
Propeller Fan Propeller Fan Propeller Fan Propeller Fan
291x2+271x4 291x2+271x4 291x2+271x4 291x2+271x4
90x6 90x6 90x6 90x6
3177x6 3177x6 3177x6 3177x6
Inverter Inverter Inverter Inverter
Top Top Top Top
Ø22.2(7/8) Ø22.2(7/8) Ø22.2(7/8) Ø22.2(7/8)
Ø44.5(1 3/4) Ø44.5(1 3/4) Ø44.5(1 3/4) Ø44.5(1 3/4)
(1280 * 1555 * 730)x3 (1280 * 1555 * 730)x3 (1280 * 1555 * 730)x3 (1280 * 1555 * 730)x3
(50.4 * 61.2 * 28.7)x3 (50.4 * 61.2 * 28.7)x3 (50.4 * 61.2 * 28.7)x3 (50.4 * 61.2 * 28.7)x3
300x3 300x3 300x3 300x3
661.4x3 661.4x3 661.4x3 661.4x3
CV 38X5C CV 38X5C CV 38X5C CV 38X5C
CVV-SB 1.25X2C CVV-SB 1.25X2C CVV-SB 1.25X2C CVV-SB 1.25X2C
R22 R22 R22 R22
L.E.V L.E.V L.E.V L.E.V
3 / 380 ~ 415 / 50 3 / 380 ~ 415 / 50 3 / 380 ~ 415 / 50 3 / 380 ~ 415 / 50
