LG multi V PLUS

192 Outdoor Unit
Specifications
380V, Cooling Only(60Hz)
Notes:
1. Capacities are based on the following conditions:
Cooling * Indoor temp. 27°C[80.6°F]DB/ 19°C[66.2°F]WB
* Outdoor temp. 35°C[95°F]DB/ 24°C[75.2°F]WB
* Interconnecting Piping Length 7.5m
* Level Difference of Zero
2. Capacities are net capacities
3. Due to our policy of innovation some specifications may be changed without notification
4. L.E.V.:Linear Expansion Valve
Conversion Formula
Kcal/h= kW x 860
Btu/h = kW x 3412
cfm = m
3
/min x 35.3
HP
Model Name Combination Unit
Independent Unit
Capacity Cooling W
kcal/h
Btu/h
Heating W
kcal/h
Btu/h
Input Cooling kW
Heating kW
Casing Color
Heat Exchanger
Compressor Type
Maker
Piston Displacement cm
2
/rev
Number of Revolution r.p.m
Motor Output x Number W
Starting Method
Oil Type
Oil Charge CC
Fan Type
Motor Output x Number W
Air Flow Rate(High) cmm
cfm
Drive
Discharge Side / Top
Pipe Connctions Liquid Pipes mm(inch)
Gas Pipes mm(inch)
Dimensions (W*H*D) mm
inch
Net Weight kg
lbs
Power Supply Cable mm
2
Transmission Cable mm
2
Refigerant Refigerant name
Control
Power Supply Ø / V / Hz
12 14 16 18
LRUV1209T0 LRUV1409T0 LRUV1609TS0 LRUV1809TS0
LRUV1209T0 LRUV1409T0 LRUV809TS0 LRUV1009TS0
LRUC809TS0 LRUC809TS0
33,600 39,200 44,800 50,400
28,900 33,700 38,500 43,300
114,700 133,800 152,900 172,000
----
----
----
11.8 13.9 14 15.9
----
WARM GRAY WARM GRAY WARM GRAY WARM GRAY
Louver Fin Louver Fin Louver Fin Louver Fin
Scroll Scroll Scroll Scroll
LG LG LG LG
77.87+110 77.87+110 77.87+110x3 77.87+110x3
3472, 3500 3472, 3500 (3472, 3500)+(3500, 3500) (3472, 3500)+(3500, 3500)
4309+5700 4309+5700 (4309+5700)+(5700+5700) (4309+5700)+(5700+5700)
Direct on Line Direct on Line Direct on Line Direct on Line
SUNISO 4GSI SUNISO 4GSI SUNISO 4GSI SUNISO 4GSI
2325 ±10, 2325 ±10 2325 ±10, 2325 ±10 2325 ±10, (2325 ±10)x3 2325 ±10, (2325 ±10)x3
Propeller Fan Propeller Fan Propeller Fan Propeller Fan
291x2 291x2 291x2+271x2 291x2+271x2
90x2 90x2 90x4 90x4
3177x2 3177x4 3177x4 3177x4
Inverter Inverter Inverter Inverter
Top Top Top Top
Ø12.7(1/2) Ø12.7(1/2) Ø19.05(3/4) Ø19.05(3/4)
Ø28.58(1 1/8) Ø28.58(1 1/8) Ø38.1(1 1/2) Ø38.1(1 1/2)
1280 * 1555 * 730 1280 * 1555 * 730
(1280 * 1555 * 730)x2 (1280 * 1555 * 730)x2
50.4 * 61.2 * 28.7 50.4 * 61.2 * 28.7 (50.4 * 61.2 * 28.7)x2 (50.4 * 61.2 * 28.7)x2
300 300 300x2 300x2
661.4 661.4 661.4x2 661.4x2
CV 8X5C CV 8X5C CV 14X5C CV 14X5C
CVV-SB 1.25X2C CVV-SB 1.25X2C CVV-SB 1.25X2C CVV-SB 1.25X2C
R22 R22 R22 R22
L.E.V L.E.V L.E.V L.E.V
3, 380, 60 3, 380, 60 3, 380, 60 3, 380, 60
