LG multi V PLUS

194 Outdoor Unit
Specifications
380V, Cooling Only(60Hz)
Notes:
1. Capacities are based on the following conditions:
Cooling * Indoor temp. 27°C[80.6°F]DB/ 19°C[66.2°F]WB
* Outdoor temp. 35°C[95°F]DB/ 24°C[75.2°F]WB
* Interconnecting Piping Length 7.5m
* Level Difference of Zero
2. Capacities are net capacities
3. Due to our policy of innovation some specifications may be changed without notification
4. L.E.V.:Linear Expansion Valve
Conversion Formula
Kcal/h= kW x 860
Btu/h = kW x 3412
cfm = m
3
/min x 35.3
HP
Model Name Combination Unit
Independent Unit
Capacity Cooling W
kcal/h
Btu/h
Heating W
kcal/h
Btu/h
Input Cooling kW
Heating kW
Casing Color
Heat Exchanger
Compressor Type
Maker
Piston Displacement cm
2
/rev
Number of Revolution r.p.m
Motor Output x Number W
Starting Method
Oil Type
Oil Charge CC
Fan Type
Motor Output x Number W
Air Flow Rate(High) cmm
cfm
Drive
Discharge Side / Top
Pipe Connctions Liquid Pipes mm(inch)
Gas Pipes mm(inch)
Dimensions (W*H*D) mm
inch
Net Weight kg
lbs
Power Supply Cable mm
2
Transmission Cable mm
2
Refigerant Refigerant name
Control
Power Supply Ø / V / Hz
28 30 32 34
LRUV2809TR0 LRUV3009TR0 LRUV3209TR0 LRUV3409TR0
LRUV809TR0 LRUV1009TR0 LRUV1209TR0 LRUV1409TR0
LRUC1009TR0 LRUC1009TR0 LRUC1009TR0 LRUC1009TR0
LRUC1009TR0 LRUC1009TR0 LRUC1009TR0 LRUC1009TR0
78,400 84,000 89,600 95,200
67,400 72,200 77,100 81,900
267,500 286,600 305,700 324,800
----
----
----
24.8 26.7 29.6 31.7
----
WARM GRAY WARM GRAY WARM GRAY WARM GRAY
Louver Fin Louver Fin Louver Fin Louver Fin
Scroll Scroll Scroll Scroll
LG LG LG LG
77.87+110x5 77.87+110x5 77.87+110x5 77.87+110x5
(3472, 3500)+(3500, 3500)x2 (3472, 3500)+(3500, 3500)x2 (3472, 3500)+(3500, 3500)x2 (3472, 3500)+(3500, 3500)x2
(4309+5700)+(5700+5700)x2 (4309+5700)+(5700+5700)x2 (4309+5700)+(5700+5700)x2 (4309+5700)+(5700+5700)x2
Direct on Line Direct on Line Direct on Line Direct on Line
SUNISO 4GSI SUNISO 4GSI SUNISO 4GSI SUNISO 4GSI
2325 ±10, (2325 ±10)x5 2325 ±10, (2325 ±10)x5 2325 ±10, (2325 ±10)x5 2325 ±10, (2325 ±10)x5
Propeller Fan Propeller Fan Propeller Fan Propeller Fan
291x2+271x4 291x2+271x4 291x2+271x4 291x2+271x4
90x6 90x6 90x6 90x6
3177x6 3177x6 3177x6 3177x6
Inverter Inverter Inverter Inverter
Top Top Top Top
Ø22.2(7/8) Ø22.2(7/8) Ø22.2(7/8) Ø22.2(7/8)
Ø44.5(1 3/4) Ø44.5(1 3/4) Ø44.5(1 3/4) Ø44.5(1 3/4)
(1280 * 1555 * 730)x3 (1280 * 1555 * 730)x3 (1280 * 1555 * 730)x3 (1280 * 1555 * 730)x3
(50.4 * 61.2 * 28.7)x3 (50.4 * 61.2 * 28.7)x3 (50.4 * 61.2 * 28.7)x3 (50.4 * 61.2 * 28.7)x3
300x3 300x3 300x3 300x3
661.4x3 661.4x3 661.4x3 661.4x3
CV 38X5C CV 38X5C CV 38X5C CV 38X5C
CVV-SB 1.25X2C CVV-SB 1.25X2C CVV-SB 1.25X2C CVV-SB 1.25X2C
R22 R22 R22 R22
L.E.V L.E.V L.E.V L.E.V
3 / 380 / 60 3 / 380 / 60 3 / 380 / 60 3 / 380 / 60
