LG multi V PLUS

Service Manual 197
Specifications
1.2.2 Heat Pump
380V, Heat Pump(60Hz)
Notes:
1. Capacities are based on the following conditions:
Cooling * Indoor temp. 27°C[80.6°F]DB/ 19°C[66.2°F]WB
* Outdoor temp. 35°C[95°F]DB/ 24°C[75.2°F]WB
* Interconnecting Piping Length 7.5m
* Level Difference of Zero
Heating * Indoor temp. 20°C[68°F]DB/ 15°C[59°F]WB
* Outdoor temp. 7°C[44.6°F]DB/ 6°C[42.8°F]WB
* Interconnecting Piping Length 7.5m
* Level Difference of Zero
2. Capacities are net capacities
3. Due to our policy of innovation some specifications may be changed without notification
4. L.E.V.:Linear Expansion Valve
Conversion Formula
Kcal/h= kW x 860
Btu/h = kW x 3412
cfm = m
3
/min x 35.3
HP
Model Name Combination Unit
Independent Unit
Capacity Cooling W
kcal/h
Btu/h
Heating W
kcal/h
Btu/h
Input Cooling kW
Heating kW
Casing Color
Heat Exchanger
Compressor Type
Maker
Piston Displacement cm
2
/rev
Number of Revolution r.p.m
Motor Output x Number W
Starting Method
Oil Type
Oil Charge CC
Fan Type
Motor Output x Number W
Air Flow Rate(High) cmm
cfm
Drive
Discharge Side / Top
Pipe Connctions Liquid Pipes mm(inch)
Gas Pipes mm(inch)
Dimensions (W*H*D) mm
inch
Net Weight kg
lbs
Power Supply Cable mm
2
Transmission Cable mm
2
Refigerant Refigerant name
Control
Power Supply Ø / V / Hz
56 810
LRUN509T0 LRUN609T0 LRUN809T0 LRUN1009T0
LRUN509T0 LRUN609T0 LRUN809T0 LRUN1009T0
14,000 16,000 22,400 28,000
12,000 13,800 19,300 24,100
47,800 54,600 76,400 95,500
15,800 18,000 25,200 31,500
13,600 15,500 21,700 27,100
53,900 61,400 86,000 107,500
4.6 5.7 7 8.9
5.1 6.1 6.8 8.6
WARM GRAY WARM GRAY WARM GRAY WARM GRAY
Louver Fin Louver Fin Louver Fin Louver Fin
Scroll Scroll Scroll Scroll
LG LG LG LG
77.87 77.87 77.87+110 77.87+110
3472 3472 3472, 3500 3472, 3500
4309x1 4309x1 4309+5700 4309+5700
Direct on Line Direct on Line Direct on Line Direct on Line
SUNISO 4GSI SUNISO 4GSI SUNISO 4GSI SUNISO 4GSI
2325 ± 10 2325 ± 10
2325 ± 10, 2325 ± 10 2325 ± 10, 2325 ± 10
Propeller Fan Propeller Fan Propeller Fan Propeller Fan
291x1 291x1 291x2 291x2
90 90 90x2 90x2
3177 3177 3177x2 3177x2
Inverter Inverter Inverter Inverter
Top Top Top Top
Ø9.52(3/8) Ø9.52(3/8) Ø12.7(1/2) Ø12.7(1/2)
Ø19.05(3/4) Ø22.2(7/8) Ø28.58(1 1/8) Ø28.58(1 1/8)
806 * 1555 * 730 806 * 1555 * 730 1280 * 1555 * 730 1280 * 1555 * 730
31.7 * 61.2 * 28.7 31.7 * 61.2 * 28.7 50.4 * 61.2 * 28.7 50.4 * 61.2 * 28.7
150 150 300 300
330.7 330.7 661.4 661.4
CV 5.5X5C CV 5.5X5C CV 8X5C CV 8X5C
CVV-SB 1.25X2C CVV-SB 1.25X2C CVV-SB 1.25X2C CVV-SB 1.25X2C
R22 R22 R22 R22
L.E.V L.E.V L.E.V L.E.V
3 / 380 / 60 3 / 380 / 60 3 / 380 / 60 3 / 380 / 60
