LG multi V PLUS Service Manual

20
Power Supply: Outdoor Unit (3Ø, 220V, 60Hz)
■ Cooling Only
■ Heat Pump
Unit
System(HP)
Model
Product Charge kg
CF(Correction Factor) kg
Max. Connectable No. of Indoor Units
Net Weight kg(lbs)
Dimensions (W x H x D) mm(inch)
Pipe Connections
Liquid Pipes(mm(inch))
Gas Pipes(mm(inch))
1 Outdoor Unit
81012
LRUV80BT0 LRUV100BT0 LRUV120BT0
10 10 10
-1 -1 -1
13 16 16
300(661.4) 300(661.4) 300(661.4)
1280 x 1555 x 730 1280 x 1555 x 730 1280 x 1555 x 730
(50.4 x 61.2 x 28.7) (50.4 x 61.2 x 28.7) (50.4 x 61.2 x 28.7)
Ø12.7(1/2) Ø12.7(1/2) Ø12.7(1/2)
Ø28.58(1
1
/8) Ø28.58(1
1
/8) Ø28.58(1
1
/8)
Unit
System(HP)
Model
Product Charge kg
CF(Correction Factor) kg
Max. Connectable No. of Indoor Units
Net Weight kg(lbs)
Dimensions (W x H x D) mm(inch)
Pipe Connections
Liquid Pipes(mm(inch))
Gas Pipes(mm(inch))
1 Outdoor Unit
810 12
LRUN80BT0 LRUN100BT0 LRUN120BT0
10 10 10
-1 -1 -1
13 16 16
300(661.4) 300(661.4) 300(661.4)
1280 x 1555 x 730 1280 x 1555 x 730 1280 x 1555 x 730
(50.4 x 61.2 x 28.7) (50.4 x 61.2 x 28.7) (50.4 x 61.2 x 28.7)
Ø12.7(1/2) Ø12.7(1/2) Ø12.7(1/2)
Ø28.58(1
1
/
8) Ø28.58(1
1
/
8) Ø28.58(1
1
/
8)
