Service Manual 305
Exploded View & Replacement Parts List
PART No.
130911 CABINET ASSEMBLY,INDOOR 3091A10024A 3091A10024A 3091A10024A
146811 MOTOR ASSEMBLY,STEP 4681AR2727G 4681AR2727G 4681AR2727G
152312 FILTER ASSEMBLY,AIR CLEANER_1 5231A10003A 5231A10003A 5231A10003A
158591 PUMP ASSEMBLY,WATER 5859A10001A 5859A10001A 5859A10001A
137211 PANEL ASSEMBLY,FRONT 3721A10069K 3721A10069J 3721A10069J
249951 CONTROL BOX ASSEMBLY,INDDOR 4995A11006A 4995A11006B 4995A11006C
263230 THERMISTOR ASSEMBLY(ROOM) 6323AQ3214P 6323AQ3214P 6323AQ3214P
263230 THERMISTOR ASSEMBLY(PIPE_IN) 6323AQ3226E 6323AQ3226E 6323AQ3226E
263230 THERMISTOR ASSEMBLY(PIPE_OUT) 6323AQ3226V 6323AQ3226V 6323AQ3226V
266012 SWITCH ASSEMBLY,FLOAT 6601A20001E 6601A20001E 6601A20001E
267110 REMOTE CONTROLLER ASSEMBLY 6711A10002A 6711A10002Q 6711A10002Q
268712 PWB(PCB) ASSEMBLY,DISPLAY 6871A20096B 6871A20096B 6871A20096B
268714 PWB(PCB)ASSEMBLY,MAIN 6871A10187J 6871A10148W 6871A10148K
330870 DRAIN PAN ASSEMBLY 3087A10005A 3087A10005A 3087A10005A
346810 MOTOR ASSEMBLY,INDOOR 4681A20003V 4681A20003V 4681A20003V
352115 TUBE ASSEMBLY,EVAPORATOR IN 5211A10303A 5211A10303A 5211A10303A
352116 TUBE ASSEMBLY,EVAPORATOR OUT 5211A20230D 5211A20230D 5211A20230D
354210 EVAPORATOR ASSEMBLY,FIRST 5421A10011A 5421A10011A 5421A10011A
359011 FAN ASSEMBLY,CROSS FLOW 5901AR2441A 5901AR2441A 5901AR2441A
435310 GRILLE ASSEMBLY,INLET 3531A10062D 3531A10062D 3531A10062D
W0CZZ CAPACITOR,DRAWING 3H00671E 3H00671E 3H00671E
152510 DRAIN TUBE ASSEMBLY_1 5251AP2984A 5251AP2984A 5251AP2984A
152510 DRAIN ASSEMBLY,TUBE_2 5251A20001A 5251A20001A 5251A20001A
266090 H.V ASSEMBLY - 6609A20005C 6609A20005C
159830 AIR CLEANER ASSEMBLY - 5983A10006C 5983A10006C
LOCATION
No.
DESCRIPTION
REMARK
LRNN096TCA0 LRNV092TCC0 LRNV122TCC0
To Next Page
