LG multi V PLUS

Service Manual 317
Explodede View & Replacement Parts List
LRNV486TDA0 LRNN486TDA0
130412 BASE ASSEMBLY,WELD[INDOOR] 3041A10016A 3041A10016A
130911 CABINET ASSEMBLY,WELD 3091A10030D 3091A10030A
130911 CABINET ASSEMBLY,WELD 3091A10030E 3091A10030B
130911 CABINET ASSY,INDOOR 3091A10031C 3091A10031A
130911 CABINET ASSY,INDOOR 3091A10031D 3091A10031B
137211 PANEL ASSEMBLY,FRONT(INDOOR) 3721A10025B 3721A10025A
135511 COVER 3550A20050A 3550A20050A
135802 DOOR 3580A20005A 3580A20005A
140570 LOCKER 4056A20001B 4056A20001B
146811 MOTOR ASSEMBLY,STEP 4681A20055A 4681A20055A
152510 DRAIN ASSEMBLY,TUBE 5251A20002B 5251A20002B
158591 PUMP,WATER 5858A10001G 5858A10001G
158591 PUMP ASSEMBLY,WATER 5859A20001D 5859A20001D
249941 CONTROL BOX,INDOOR 4994A10020A 4994A10020A
249951 CONTROL BOX ASSEMBLY,INDOOR 4995A10152T 4995A10152V
263230 THERMISTOR ASSEMBLY 6323A30002A 6323A30002A
263230 THERMISTOR ASSEMBLY 6323A30004C 6323A30004C
263230 THERMISTOR ASSEMBLY 6323AQ3226T 6323AQ3226T
266012 SWITCH ASSY,FLOAT 6601A20001F 6601A20001F
152312 FILTER ASSY,AIR CLEANER 5231A10004A 5231A10004A
152510 HOSE ASSEMBLY,DRAIN 5251AP2984A 5251AP2984A
267110 REMOTE CONTROLLER ASSEMBLY 6711A20081M 6711A20081J
268712 PWB(PCB) ASSY,DISPLAY 6871A20096C 6871A20096C
268714 PWB(PCB) ASSEMBLY,MAIN 6871A10187W 6871A10187G
330870 DRAIN PAN ASSEMBLY 3087A10006A 3087A10006A
346810 MOTOR ASSEMBLY,INDOOR 4681A20006H 4681A20006H
349600 MOUNT,MOTOR 4960AP7265A 4960AP7265A
352114 TUBE ASSEMBLY,DISTRIBUTOR 5211A10299A 5211A10299A
352118 TUBE ASSEMBLY,MENIFOLD(INDOOR) 5211A20251B 5211A20251B
352118 TUBE ASSEMBLY,MENIFOLD(INDOOR) 5211A20251G 5211A20251G
354211 EVAPORATOR ASSY,BENDING 5421A10016A 5421A10016A
354211 EVAPORATOR ASSY,BENDING 5421A10016B 5421A10016B
359012 FAN ASSEMBLY,TURBO 5900A10003B 5900A10003B
435310 GRILLE ASSY,INLET 3531A10066A 3531A10066A
55211G TUBE ASSEMBLY,EXPANSION 5211A10298B 5211A10298B
648600 CLAMP,CAPACITOR 4H00442C 4H00442C
W0CZZ CAPACITOR,DRAWING 2A00986D 3H00660M
W6640 TERMINAL BLOCK 6640W3A009A 6640W3A009A
PART NO.
DESCRIPTION
REMARK
LOCATION
NO.
