LG multi V PLUS

Service Manual 319
Exploded View & Replacement Parts List
LRNV182BHA0 LRNV212BHA0 LRNV242BHA0 LRNV246BHA0
359012 FAN ASSEMBLY,BLOWER 5901A10028T 5901A10028T 5901A10028T 5901A10028T
336600 HOUSING (MECH),WRAPPER 3660A20017A 3660A20017A 3660A20017A 3660A20017A
336600 HOUSING (MECH),WRAPPER 3660A20018A 3660A20018A 3660A20018A 3660A20018A
346810 MOTOR ASSEMBLY,INDOOR 4681A10013C 4681A10013C 4681A10013C 4681A10013C
359012 FAN ASSEMBLY,BLOWER 5901A10026A 5901A10026A 5901A10026A 5901A10026A
W0CZZ CAPACITOR,DRAWING 2A00986D 2A00986D 2A00986D 2A00986D
354210 EVAPORATOR ASSEMBLY,FIRST 5421A20100B 5421A20100B 5421A20100B 5421A20100B
352118 TUBE ASSEMBLY,MENIFOLD(INDOOR) 5211A20465D 5211A20465D 5211A20465D 5211A20465D
352115 TUBE ASSEMBLY,EVAPORATOR IN 5211A10305A 5211A10305A 5211A10305A 5211A10305A
330870 DRAIN PAN ASSEMBLY 3087A10008D 3087A10008D 3087A10008D 3087A10008D
249951 CONTROL BOX ASSEMBLY,INDOOR 4995A10127K 4995A10127L 4995A10127M 4995A10127N
268714 PWB(PCB) ASSEMBLY,MAIN 6871A10166G 6871A10166H 6871A10166J 6871A10127N
263230 THERMISTOR ASSY 6323AQ3226G 6323AQ3226G 6323AQ3226G 6323AQ3226G
263230 THERMISTOR ASSEMBLY 6323A30004D 6323A30004D 6323A30004D 6323A30004D
263230 THERMISTOR ASSEMBLY 6323AQ3226W 6323AQ3226W 6323AQ3226W 6323AQ3226W
267110 REMOTE CONTROLLER ASSEMBLY 6711A20043E 6711A20043E 6711A20043E 6711A20043E
152302 FILTER(MECH),A/C 5230A30001M 5230A30001M 5230A30001M 5230A30001M
158591 PUMP ASSEMBLY,WATER 5859A20002A 5859A20002A 5859A20002A 5859A20002A
266012 SWITCH ASSEMBLY,FLOAT 6601A20001E 6601A20001E 6601A20001E 6601A20001E
137214 PANEL ASSEMBLY,UPPER 3721A20177C 3721A20177C 3721A20177C 3721A20177C
137213 PANEL ASSEMBLY,SIDE 3721A20178C 3721A20178C 3721A20178C 3721A20178C
137213 PANEL ASSEMBLY,SIDE 3721A20179D 3721A20179D 3721A20179D 3721A20179D
437213 PANEL ASSEMBLY,REAR(INDOOR) 3721A21004C 3721A21007C 3721A21010C 3721A21004C
437213 PANEL ASSEMBLY,REAR(INDOOR) 3721A21005C 3721A21005C 3721A21005C 3721A21005C
149900 HANGER 4990A20004A 4990A20004A 4990A20004A 4990A20004A
PART NO.
DESCRIPTION
REMARK
LOCATION
NO.
