LG multi V PLUS

322 Indoor Unit
Exploded View & Replacement Parts List
LRNV282BGA0 LRNV382BGA0 LRNN286BGA0 LRNN366BGA0
359012 FAN ASSEMBLY,BLOWER 5901A10028U 5901A10028A 5901A10028V 5901A10028U
336600 HOUSING (MECH),WRAPPER 3660A20019A 3660A20019A 3660A20019A 3660A20019A
336600 HOUSING (MECH),WRAPPER 3660A20020A 3660A20020A 3660A20020A 3660A20020A
346810 MOTOR ASSEMBLY,INDOOR 4681A10013P 4681A10013A 4681A10013A 4681A10013P
359012 FAN ASSEMBLY,BLOWER 5901A10026A 5901A10026A 5901A10026A 5901A10026A
W0CZZ CAPACITOR,DRAWING 2A00986D 2A00986D 2A00986D 2A00986D
354210 EVAPORATOR ASSEMBLY,FIRST 5421A10027C 5421A10027C 5421A10027C 5421A10027C
352118 TUBE ASSEMBLY,MENIFOLD(INDOOR) 5211A20416G 5211A20416H 5211A20416G 5211A20416G
55211G TUBE ASSEMBLY,EXPANSION 5211A10426A 5211A10426B 5211A10426A 5211A10426A
330870 DRAIN PAN ASSEMBLY 3087A10008C 3087A10008C 3087A10008C 3087A10008C
249951 CONTROL BOX ASSEMBLY,INDOOR 4995A10127N 4995A10127U 4995A10173C 4995A10127Z
268714 PWB(PCB) ASSEMBLY,MAIN 6871A10166K 6871A10166M 6871A10217C 6871A10217D
263230 THERMISTOR ASSY 6323AQ3226G 6323AQ3226G 6323AQ3226G 6323AQ3226G
263230 THERMISTOR ASSEMBLY 6323A30004D 6323A30004D 6323A30004D 6323A30004D
263230 THERMISTOR ASSEMBLY 6323AQ3226W 6323AQ3226W 6323AQ3226W 6323AQ3226W
267110 REMOTE CONTROLLER ASSEMBLY 6711A20043E 6711A20043E 6711A20043D 6711A20043Q
152302 FILTER(MECH),A/C 5230A30001L 5230A30001L 5230A30001L 5230A30001L
158591 PUMP ASSEMBLY,WATER 5859A20002A 5859A20002A 5859A20002A 5859A20002A
266012 SWITCH ASSEMBLY,FLOAT 6601A20001E 6601A20001E 6601A20001E 6601A20001E
137214 PANEL ASSEMBLY,UPPER 3721A20180C 3721A20180C 3721A20180C 3721A20180C
137213 PANEL ASSEMBLY,SIDE 3721A20181C 3721A20181C 3721A20181C 3721A20181C
137213 PANEL ASSEMBLY,SIDE 3721A20183C 3721A20183C 3721A20183C 3721A20183C
437213 PANEL ASSEMBLY,REAR(INDOOR) 3721A2006C 3721A2006C 3721A21006C 3721A21006C
437213 PANEL ASSEMBLY,REAR(INDOOR) 3721A2007C 3721A2007C 3721A21007C 3721A21007C
149900 HANGER 4990A20004A 4990A20004A 4990A20004A 4990A20004A
PART NO.
DESCRIPTION
REMARK
LOCATION
NO.
