LG multi V PLUS

Service Manual 325
Exploded View & Replacement Parts List
LRNN486BEA0 LRNV482BEA0
PART No.
359012 FAN ASSEMBLY,BLOWER 5901A20001F 5901A20001E
336610 HOUSING ASSY (MECH) 3661A10009E 3661A20001E
336610 HOUSING ASSY (MECH) 3661A10009F 3661A20001F
346810 MOTOR ASSEMBLY,INDOOR 4681A20005K 4681A20005J
W0CZZ CAPACITOR,DRAWING 0CZZA20001C 0CZZA20001C
359012 FAN ASSEMBLY,BLOWER 5901A10015E 5833A20001A
359012 FAN ASSEMBLY,BLOWER 5901A10015F 5833A20001B
354210 EVAPORATOR ASSEMBLY,FIRST 5421A20008A 5421A20008A
352118 TUBE ASSEMBLY,MENIFOLD(INDOOR)
5211A30076B 5211A30076B
55211G TUBE ASSEMBLY,EXPANSION 5211A10416B 5211A10416B
330870 DRAIN PAN ASSEMBLY 3087A20023A 3087A20023A
249951 CONTROL BOX ASSEMBLY,INDOOR 4995A10127T 4995A10127P
268714 PWB(PCB) ASSEMBLY,MAIN 6871A10167D 6871A10167B
263230 THERMISTOR ASSY 6323AQ3226G 6323AQ3226G
263230 THERMISTOR ASSEMBLY 6323A30004D 6323A30004D
263230 THERMISTOR ASSEMBLY 6323AQ3226W 6323AQ3226W
267110 REMOTE CONTROLLER ASSEMBLY 6711A10002D 6711A20043E
152302 FILTER(MECH),A/C 5230A30001A 5230A30001A
158591 PUMP ASSEMBLY,WATER 5859A10002A 5859A10002A
266012 SWITCH ASSEMBLY,FLOAT 6601A20001E 6601A20001E
137214 PANEL ASSEMBLY,UPPER 3721A20184A 3721A20184A
137213 PANEL ASSEMBLY,SIDE 3721A20185A 3721A20185A
137213 PANEL ASSEMBLY,SIDE 3721A20186A 3721A20186A
437213 PANEL ASSEMBLY,REAR(INDOOR) 3721A21008A 3721A21008A
237205 PANEL REAR 3720A30011A 3720A30011A
149900 HANGER 4990AP7280E 4990AP7280E
149900 HANGER 4990AP7280F 4990AP7280F
LOCATION No. DESCRIPTION
REMARK
