LG multi V PLUS

Service Manual 331
Exploded View & Replacement Parts List
LRNN092SRA0 LRNN122SRA0
PART No.
131410 CHASSIS ASSEMBLY 3141A20005E 3141A20005E
346810 MOTOR ASSEMBLY,INDOOR 4681A20048C 4681A20048C
135516 COVER ASSEMBLY,MOTOR 3551A20050A 3551A20050A
342800 BEARING 4280A20004A 4280A20004A
359011 FAN ASSEMBLY, CROSS FLOW 5901A20007A 5901A20007A
135311 GRILLE ASSEMBLY,DISCHARGE(INDOOR) 3531A10192E 3531A10192E
146811 MOTOR ASSEMBLY,STEP 4681A20055A 4681A20055A
159901 VANE,HORIZONTAL 5990A20007A 5990A20007A
268712 PWB(PCB)ASSEMBLY,DISPLAY 6871A20227J 6871A20227J
352150 HOSE ASSEMBLY,DRAIN 5251AR2575F 5251AR2575F
35211B TUBE ASSEMBLY,TUBING 5211A10324A 5211A10324A
263230
THERMISTOR ASSEMBLY(ROOM,PIPE IN) 6323A20004M 6323A20004M
263230 THERMISTOR ASSEMBLY(PIPE-OUT) 6323AQ3226Z 6323AQ3226Z
249951 CONTROL BOX ASSEMBLY,INDOOR 4995A20274S 4995A20274T
268715 PWB(PCB)ASSEMBLY,MAIN(AC) 6871A20274A 6871A20274A
268716 PWB(PCB)ASSEMBLY,MAIN(DC) 6871A20581A 6871A20581B
W0CZZ CAPACITOR,DRAWING 3H01487A 3H01487A
135312 GRILL ASSEMBLY,FRONT(INDOOR) 3531A10118W 3531A10118W
135314 GRILL ASSEMBLY,INLET SUB 3531A10117U 3531A10117U
152302 FILTER(MECH),A/C 5230A20014C 5230A20014C
733010 PLATE 1H00843A 1H00843A
267110 REMOTE CONTROLLER ASSEMBLY 6711A20010B 6711A20010B
352115 TUBE ASSEMBLY, EVAPORATOR IN 5211A10310A 5211A10310A
352116 TUBE ASSEMBLY, EVAPORATOR OUT 5211A20911A 5211A20911A
354210 EVAPORATOR ASSEMBLY,FIRST 5421A20086A 5421A20086A
LOCATION No. DESCRIPTION
REMARK
