LG multi V PLUS

Service Manual 333
Exploded View & Replacement Parts List
LRNN186STA0 LRNN182STA0 LRNV186STA0 LRNV182STL0
131410 CHASSIS ASSEMBLY 3141A10002A 3141A10002A 3141A10002A 3141A10002A
346810 MOTOR ASSEMBLY,INDOOR 4681A20003D 4681A20003B 4681A20003D 4681A20003B
135516 COVER ASSEMBLY,MOTOR 3551A20099C 3551A20099C 3551A20099C 3551A20099C
342800 BEARING 4280A20004A 4280A20004A 4280A20004A 4280A20004A
359011 FAN ASSEMBLY, CROSS FLOW 5901A20008A 5901A20008A 5901A20008A 5901A20008A
135311 GRILLE ASSEMBLY,DISCHARGE(INDOOR) 3531A10231Y 3531A10231Y 3531A10231Y 3531A10231Y
146811 MOTOR ASSEMBLY,STEP 4681A20055A 4681A20055A 4681A20055A 4681A20055A
159901 VANE,HORIZONTAL 5990A20008A 5990A20008A 5990A20008A 5990A20008A
159901 VANE,HORIZONTAL 5990A20009A 5990A20009A 5990A20009A 5990A20009A
268712 PWB(PCB)ASSEMBLY,DISPLAY 6871A20227M 6871A20227M 6871A20227M 6871A20227M
352150 HOSE ASSEMBLY,DRAIN 5251AR2575F 5251AR2575F 5251AR2575F 5251AR2575F
35211B TUBE ASSEMBLY,TUBING 5211A10324B 5211A10324B 5211A10324B 5211A10324B
263230 THERMISTOR ASSEMBLY(ROOM,PIPE IN)
6323A20004M 6323A20004M 6323A20004M 6323A20004M
263230 THERMISTOR ASSEMBLY(PIPE-OUT)
6323AQ3226Z 6323AQ3226Z 6323AQ3226Z 6323AQ3226Z
249951 CONTROL BOX ASSEMBLY,INDOOR 4995A20274Y 4995A20274U 4995A12003M 4995A20274V
268715 PWB(PCB)ASSEMBLY,MAIN(AC) 6871A20274A 6871A20274A 6871A20274A 6871A20274A
268716 PWB(PCB)ASSEMBLY,MAIN(DC) 6871A20581J 6871A20581C 6871A20581T 6871A20581P
W0CZZ CAPACITOR,DRAWING 3H01487G 3H01487G 3H01487G 3H01487G
135312 GRILL ASSEMBLY,FRONT(INDOOR) 3531A20207H 3531A20207H 3531A20207M 3531A20207N
135314 GRILL ASSEMBLY,INLET SUB 3531A20107L 3531A20107L 3531A20233E 3531A20233E
152302 FILTER(MECH),A/C 5230A20001A 5230A20001A 5230A20001A 5230A20001A
733010 PLATE 3301A10002A 3301A10002A 3301A10002A 3301A10002A
267110 REMOTE CONTROLLER ASSEMBLY 6711A20010B 6711A20010B 6711A20010A 6711A20010E
352115 TUBE ASSEMBLY, EVAPORATOR IN 5211A14006B 5211A14006B 5211A14006B 5211A14006B
352116
TUBE ASSEMBLY, EVAPORATOR OUT 5211A30057E 5211A30057E 5211A30057E 5211A30057E
354210 EVAPORATOR ASSEMBLY,FIRST 5421A20010E 5421A20010D 5421A20010D 5421A20010D
PART NO.
DESCRIPTION
REMARK
LOCATION
NO.
