LG multi V PLUS

Service Manual 335
Exploded View & Replacement Parts List
LRNV072SUD0 LRNV092SUD0 LRNV122SUD0 LRNN126SUR0
131410 CHASSIS ASSEMBLY 3141A20007E 3141A20007E 3141A20007E 3141A20007E
346810 MOTOR ASSEMBLY,INDOOR 4681A20048F 4681A20048F 4681A20048F 4681A20048L
342800 BEARING 4280A20004A 4280A20004A 4280A20004A 4280A20004A
135311 GRILLE ASSEMBLY,DISCHARGE(INDOOR) 3531A10137B 3531A10137B 3531A10137B 3531A10137B
146811 MOTOR ASSEMBLY,STEP 4681A20055A 4681A20055A 4681A20055A 4681A20055B
159901 VANE,HORIZONTAL 5990A20015B 5990A20015B 5990A20015B 5990A20015B
352150 HOSE ASSEMBLY,DRAIN 5251AR1222R 5251AR1222R 5251AR1222R 5251AR1222R
359011 FAN ASSEMBLY,CROSS FLOW 5901A20016A 5901A20016A 5901A20016A 5901A20016A
354212 EVAPORATOR ASSEMBLY,FINAL 5421A20105M 5421A20105M 5421A20105M 5421A20105M
35211B TUBE ASSEMBLY,TUBING 5211A10324C 5211A10324C 5211A10324C 5211A10324C
35211B TUBE ASSEMBLY,TUBING 5211A20774C 5211A20774C 5211A20774C 5211A20774C
352114 TUBE ASSEMBLY,EVAPORATOR IN 5211A14011A 5211A14011A 5211A14011A 5211A14011A
159830 AIR CLEANER ASSEMBLY 5983A10006U 5983A10006U 5983A10006U 5983A10006U
249951 CONTROL BOX ASSEMBLY,INDOOR 4995A12003R 4995A12003S 4995A12003T 4995A12003L
249941 CONTROL BOX,INDOOR 4994A10047A 4994A10047A 4994A10047A 4994A10047A
268715 PWB(PCB) ASSEMBLY,MAIN(AC) 6871A20274A 6871A20274A 6871A20274A 6871A20274A
268716 PWB(PCB) ASSEMBLY,MAIN(DC) 6871A20172V 6871A20172X 6871A20172E 6871A20172J
263230 THERMISTOR ASSEMBLY 6323A20004M 6323A20004M 6323A20004M 6323A20004M
W0CZZ CAPACITOR,DRAWING 3H01487A 3H01487A 3H01487A 3H01487A
330860 DRAIN PAN 3086A20015A 3086A20015A 3086A20015A 3086A20015A
263230 THERMISTOR ASSEMBLY 6323AQ3226Z 6323AQ3226Z 6323AQ3226Z 6323AQ3226Z
135316 GRILLE ASSEMBLY,FRONT(INDOOR)
3531A21026L 3531A21026L 3531A21026L 3531A21026L
135313 GRILLE ASSEMBLY,INLET 3531A10331B 3531A10331B 3531A10331B 3531A10391A
263020 LCD MODULE 6306A90005A 6306A90005A 6306A90005A 6306A90005A
135080 DECORATION 3508A20034E 3508A20034E 3508A20034E 3508A20034E
668713 PWB(PCB) ASSEMBLY,SUB 6871A20259A 6871A20259A 6871A20259A 6871A20259A
668713 PWB(PCB) ASSEMBLY,SUB 6871A20258B 6871A20258B 6871A20258B 6871A20258B
146811 MOTOR ASSEMBLY,STEP 4681A20055B 4681A20055B 4681A20055B 4681A20055B
152302 FILTER(MECH),A/C 5230A20022A 5230A20022A 5230A20022A 5230A20022A
733010 PLATE 1H00843A 1H00843A 1H00843A 1H00843A
267110 REMOTE CONTROLLER ASSEMBLY 6711A20077U 6711A20077U 6711A20077U 6711A20077U
266090 H.V ASSEMBLY 6609A10005A 6609A10005A 6609A10005A 6609A10005A
PART NO.
DESCRIPTION
REMARK
LOCATION
NO.
