LG multi V PLUS

338 Indoor Unit
Exploded View & Replacement parts List
PART No.
LRNN096SPM0 LRNV092SPD0
131410 CHASSIS ASSEMBLY 3141A20004F 3141A20004F
135303 GRILLE,INLET 3530A10071D 3530A10071C
135311 GRILLE ASSEMBLY,DISCHARGE(INDOOR) 3531A20069D 3531A20069D
135311 GRILLE ASSEMBLY,DISCHARGE(INDOOR) 3531A20069E 3531A20069E
135311 GRILLE ASSEMBLY,DISCHARGE(INDOOR) 3531A20069L 3531A20069L
135313 GRILLE ASSEMBLY,INLET 3531A20113A 3531A20113M
135316 GRILLE ASSEMBLY,FRONT(INDOOR) 3531A10145S 3531A10296D
135500 COVER 3550A20060A 3550A20060A
135500 COVER 3550A20123A 3550A20123A
135500 COVER 3550A20124A 3550A20124A
135515 COVER ASSY,TOP(INDOOR) 3551A20031A 3551A20031A
144710 GEAR ASSEMBLY 4471A20001C 4471A20001C
144710 GEAR ASSEMBLY 4471A20001D 4471A20001D
146811 MOTOR ASSEMBLY,STEP 4681A20055A 4681A20055A
146811 MOTOR ASSEMBLY,STEP 4681A20055A 4681A20055A
146811 MOTOR ASSEMBLY,STEP 4681A20055A 4681A20055A
146811 MOTOR ASSEMBLY,STEP 4681A20055A 4681A20055A
147581 LOUVER,HORIZONTAL 4758A20014B 4758A20014B
147581 LOUVER,HORIZONTAL 4758A20014B 4758A20014B
147581 LOUVER,HORIZONTAL 4758A20014B 4758A20014B
152312 FILTER ASSEMBLY,AIR CLEANER 5231A20005A 5231A20005A
249951 CONTROL BOX ASSEMBLY,INDOOR 4995A20270N 4995A20270P
263230 THERMISTOR ASSEMBLY 6323A20004J 6323A20004J
263230 THERMISTOR ASSEMBLY 6323A20004J 6323A20004J
263230 THERMISTOR ASSEMBLY 6323AQ3226W 6323AQ3226W
267110 REMOTE CONTROLLER ASSEMBLY 6711A20039P 6711A20073L
268712 PWB(PCB) ASSEMBLY,DISPLAY 6871A20238B 6871A20238B
268713 PWB(PCB) ASSEMBLY,SUB 6871A30027A 6871A30027A
268714 PWB(PCB) ASSEMBLY,MAIN(DC) 6871A20676J 6871A20676T
330870 DRAIN PAN ASSEMBLY 3087A30004A 3087A30004A
346810 MOTOR ASSEMBLY,INDOOR 4681A20047B 4681A20047B
352090 AIR GUIDE 5238A10007A 5238A10007A
352115 TUBE ASSEMBLY,EXPANSION 5211A11041A 5211A11041A
352116 TUBE ASSEMBLY,EVAPORATOR OUT 5211A11042A 5211A11042A
352150 HOSE ASSEMBLY,DRAIN 5251AR1222R 5251AR1222R
359012 FAN,TURBO 5900A00003A 5900A00003A
LOCATION No. DESCRIPTION
REMARK
