LG multi V PLUS

340 Indoor Unit
Exploded View & Replacement Parts List
LRNV126SVM0 LRNN126SVM0 LRNV186SVM0 LRNN186SVM0 LRNN182SVM0
135303 GRILLE,INLET 3530A10116D 3530A10116D 3530A10116D 3530A10116D 3530A10116D
135303 GRILLE,INLET 3530A10117D 3530A10117D 3530A10117D 3530A10117D 3530A10117D
135311 GRILLE ASSEMBLY,DISCHARGE(INDOOR) 3531A20124B 3531A20124B 3531A20124B 3531A20124B 3531A20124B
135311 GRILLE ASSEMBLY,DISCHARGE(INDOOR) 3531A20125B 3531A20125B 3531A20125B 3531A20125B 3531A20125B
135316 GRILLE ASSEMBLY,FRONT(INDOOR) 3531A11018E 3531A10153Z 3531A11018E 3531A10153Z 3531A10153Z
135500 COVER 3550A20060A 3550A20060A 3550A20060A 3550A20060A 3550A20060A
135500 COVER 3550A20120B 3550A20120B 3550A20120B 3550A20120B 3550A20120B
135500 COVER 3550A20121B 3550A20121B 3550A20121B 3550A20121B 3550A20121B
146811 MOTOR ASSEMBLY,STEP 4681A20055A 4681A20055A 4681A20055A 4681A20055A 4681A20055A
146811 MOTOR ASSEMBLY,STEP 4681A20055C 4681A20055C 4681A20055C 4681A20055C 4681A20055C
147581 LOUVER,HORIZONTAL 4758A20033A 4758A20033A 4758A20033A 4758A20033A 4758A20033A
147582 LOUVER,VERTICAL 4758A20034A 4758A20034A 4758A20034A 4758A20034A 4758A20034A
152302 FILTER(MECH),A/C 5230A10006B 5230A10006B 5230A10006B 5230A10006B 5230A10006B
237900 WINDOW,DISPLAY 3790A20035A 3790A20035A 3790A20035A 3790A20035A 3790A20035A
249951 CONTROL BOX ASSEMBLY,INDOOR 4995A10098N 4995A10098Q 4995A10098P 4995A10098M 4995A10098M
263230 THERMISTOR ASSEMBLY 6323A20004J 6323A20004J 6323A20004J 6323A20004J 6323A20004J
263230 THERMISTOR ASSEMBLY 6323AQ3226V 6323AQ3226V 6323AQ3226V 6323AQ3226V 6323AQ3226V
267110 REMOTE CONTROLLER ASSEMBLY 6711A20010A 6711A20039P 6711A20010A 6711A20073N 6711A20073N
268712 PWB(PCB) ASSEMBLY,DISPLAY 6871A20250A 6871A20250A 6871A20250A 6871A20250A 6871A20250A
268713 PWB(PCB) ASSEMBLY,SUB 6871A30029A 6871A30029A 6871A30029A 6871A30029A 6871A30029A
268714 PWB(PCB) ASSEMBLY,MAIN(DC) 6871A20676Q 6871A20676L 6871A20676R 6871A20676M 6871A20676M
330870 DRAIN PAN ASSEMBLY 3087A20013A 3087A20013A 3087A20013A 3087A20013A 3087A20013A
346810 MOTOR ASSEMBLY,INDOOR 4681A20047C 4681A20047C 4681A20047C 4681A20047C 4681A20047C
346810 MOTOR ASSEMBLY,INDOOR 4681A20047D 4681A20047D 4681A20047D 4681A20047D 4681A20047D
349490 ORIFICE ASSEMBLY 4949A20002A 4949A20002A 4949A20002A 4949A20002A 4949A20002A
352115 TUBE ASSEMBLY,EVAPORATOR IN 5211A10423A 5211A10423A 5211A10423A 5211A10423A 5211A10423A
352116 TUBE ASSEMBLY,EVAPORATOR OUT 5211A20301H 5211A20301H 5211A20301H 5211A20301H 5211A20301H
352150 HOSE ASSEMBLY,DRAIN 5251AR1222R 5251AR1222R 5251AR1222R 5251AR1222R 5251AR1222R
352380 AIR GUIDE 5238A10009A 5238A10009A 5238A10009A 5238A10009A 5238A10009A
352380 AIR GUIDE 5238A10010A 5238A10010A 5238A10010A 5238A10010A 5238A10010A
354210 EVAPORATOR ASSEMBLY,FIRST 5421A20104A 5421A20104B 5421A20104A 5421A20104B 5421A20104A
359012 FAN,TURBO 5900A00004A 5900A00004A 5900A00004A 5900A00004A 5900A00004A
359012 FAN,TURBO 5900A00005A 5900A00005A 5900A00005A 5900A00005A 5900A00005A
PART NO.
DESCRIPTION
REMARK
LOCATION
NO.
