LG multi V PLUS

344 Outdoor Unit
Exploded View & Replacement Parts List
554160 COMPRESSOR SET 2520UNGV1AA 2520UNGV1AA
548490 ACCUMULATOR 4848A20001D 4848A20001D
553000 HEATER, SUMP 5300A20008A 5300A20008A
352111 TUBE ASSEMBLY, CONNECTOR 5211A22131A 5211A22131A
552201 VALVE, CHECK 3A01020D 3A01020D
552203 VALVE, SERVICE 5220A90012H 5220A90012H
552203 VALVE, SERVICE 5220A90012F 5220A90012G
566000 SWITCH, PRESSURE 6600AG3057A 6600AG3057A
552200 VALVE, EXPANSION BODY 5220A90001B 5220A90001B
552204 VALVE, SOLENOID 5220A90002A 5220A90002A
552204 VALVE, SOLENOID 5220A90008B 5220A90008B
552202 VALVE, REVERSING 5220AP3777C 5220AP3777C
159910 VALVE ASSEMBLY 5221A20004P 5221A20004P
558511 DRIER ASSEMBLY 5851A20002A 5851A20002A
565010 SENSOR ASSEMBLY 6501A20004A 6501A20004A
565010 SENSOR ASSEMBLY 6501A20004B 6501A20004B
561411 COIL ASSEMBLY, EXPANSION 6141A20009J 6141A20009J
561410 COIL ASSEMBLY, SOLENOID 6141A10001H 6141A10001H
561410 COIL ASSEMBLY, SOLENOID 6141A10001G 6141A10001G
561410 COIL ASSEMBLY, REVERSING VALVE 6141A20010F 6141A20010F
263230 THERMISTOR ASSEMBLY 6323A20009B 6323A20009B
263230 THERMISTOR ASSEMBLY 6323A20009C 6323A20009C
263230 THERMISTOR ASSEMBLY 6323A20009G 6323A20009G
546810 MOTOR ASSEMBLY, OUTDOOR 4681A10029A 4681A10029A
559010 FAN ASSEMBLY PROPELLER 5901A10029A 5901A10029A
649950 CONTROL BOX ASSEMBLY, OUTDOOR 4995A10109C 4995A10109C
668711 PWB(PCB)ASSEMBLY, MAIN(OUTDOOR) 6871A10076C 6871A10076C
668713 PWB(PCB)ASSEMBLY, SUB 6871A20133G 6871A20133G
668711 PWB(PCB)ASSEMBLY, MAIN(OUTDOOR) 6871A10145A 6871A10145A
668711 PWB(PCB)ASSEMBLY, MAIN(OUTDOOR) 6871A10146A 6871A10146A
566001 SWITCH, MAGNET 6600B000048 6600B000048
346811 MOTOR ASSEMBLY, SINGLE 4681A21001A 4681A21001A
649950 CONTROL BOX ASSEMBLY, OUTDOOR 4995A10171G 4995A10171L
668711 PWB(PCB)ASSEMBLY, MAIN(OUTDOOR) 6871A30036L 6871A30036P
261704 TRANSFORMER, POWER 6170A20016D 6170A20016D
W6200 FILTER(CIRC), EMC 6200J000057 6200J000057
W0FZZ FUSE, DRAWING 0FZZA90001F 0FZZA90001F
LRUN508T0 LRUN608T0
PART NO.
DESCRIPTION
REMARK
LOCATION NO.
