LG multi V PLUS

356 Outdoor Unit
Exploded View & Replacement Parts List
554160 COMPRESSOR SET 2520UNCV2CA
554160 COMPRESSOR SET 2520UNER2AA
548490 ACCUMULATOR ASSEMBLY(MECH) 4849A10038A
352111 TUBE ASSEMBLY,CONNECTOR 5211A11040A
553000 HEATER,SUMP 5300A20008A
553000 HEATER,SUMP 5300A20008B
w48602 CLAMP,SPRING 4H01930A
552203 VALVE,SERVICE 5220A90012A
552203 VALVE,SERVICE 5220A20042A
55211F TUBE ASSEMBLY,SOLENOIDE 5211A11023A
552201 VALVE,CHECK 3A01020L
566000 SWITCH,PRESSURE 6600AG3057A
55211F TUBE ASSEMBLY,SOLENOIDE 5211A11024A
552202 VALVE,REVERSING 5220A20039A
552204 VALVE,SOLENOID 5220A90008B
552204 VALVE,SOLENOID 5220A90002A
552200 VALVE,EXPANSION BODY 5220A90001B
159910 VALVE ASSEMBLY 5221A20004P
552201 VALVE,CHECK 3A01020D
558511 DRIER ASSEMBLY 5851A20002A
565010 SENSOR ASSEMBLY 6501A20004A
565010 SENSOR ASSEMBLY 6501A20004B
561410 COIL ASSEMBLY,REVERSING VALVE 6141A20010F
561411 COIL ASSEMBLY,EXPANSION 6141A20009J
561410 COIL ASSEMBLY,SOLENOID 6141A10001G
561410 COIL ASSEMBLY,SOLENOID 6141A10001H
561410 COIL ASSEMBLY,SOLENOID 6141A10001J
263230 THERMISTOR ASSEMBLY 6323A20009B
263230 THERMISTOR ASSEMBLY 6323A20009C
263230 THERMISTOR ASSEMBLY 6323A20009D
546810 MOTOR ASSEMBLY,OUTDOOR 4681A10029A
559010 FAN ASSEMBLY,PROPELLER 5901A10029A
649950 CONTROL BOX ASSEMBLY,OUTDOOR 4995A10164A
668711 PWB(PCB) ASSEMBLY,MAIN(OUTDOOR) 6871A30076F
668711 PWB(PCB) ASSEMBLY,MAIN(OUTDOOR) 6871A10145A
668713 PWB(PCB) ASSEMBLY,SUB 6871A20133G
668711 PWB(PCB) ASSEMBLY,MAIN(OUTDOOR) 6871A10146A
346811 MOTOR ASSEMBLY,SINGLE 4681A21001A
649950 CONTROL BOX ASSEMBLY,OUTDOOR 4995A10165A
668711 PWB(PCB) ASSEMBLY,MAIN(OUTDOOR) 6871A10206A
261704 TRANSFORMER,POWER 6170A20016A
566001 SWITCH,MAGNET 6600B000066
W0FZZ FUSE,DRAWING 0FZZA90001L
W6200 FILTER(CIRC),EMC 6200J000035
PART NO.
LRUN100BT0
DESCRIPTION
REMARK
LOCATION NO.
LRUN100BT0
