Actuator with IC Basic:
I/O specifications:
Input/Output Specification Comments
Violet Analogue feedback
0-10V (Option 7.2)
Standby power consumption:
12V, 60mA
24V, 45 mA
Ripple max. 200mV
Transaction delay 20ms
Linear feedback 0.5%
Max. current output: 1mA
It is recommendable to have
the actuator to activate its limit
switches on a regular basis, to
ensure more precise positioning
Single Hall output (PNP) (Option 7.1) Output voltage min. V
IN
- 2V
Max. current output: 12mA
For more information see fig. 5.1,
page 20
White Signal GND For correct wiring of power GND
and Signal GND see page 45
