Actuator with Parallel:
I/O specifications:
Input/Output Specification Comments
Green Endstop signal out Output voltage min. V
IN
- 2V
Source current max. 100mA
NOT potential free
Yellow Endstop signal in
Violet Parallel communication:
Violet cords must be connected
together
Standby power consumption:
12V, 60mA
24V, 45mA
No feedback available during
parallel drive
White Signal GND:
White cords must be connected
together
For correct wiring of power GND
and Signal GND see page 45
