Linksys LGS326P User Manual

6
Logging Out
By default, the application logs out after ten minutes of inactivity.
CAUTION
Unless the Running Configuration is copied to the Startup Configuration, rebooting the
device will remove all changes made since the last time the file was saved. Save the
Running Configuration to the Startup Configuration before logging off to preserve any
changes you made during this session.
When you click Quick Start > Save Your Configurations, the Configuration File Copy page
appears. Save the Running Configuration file by copying it to the Startup Configuration
file.
To log out, click Logout in the top right corner of any page. The system logs out of the device.
NOTE—When a timeout occurs or you intentionally log out of the system, a message appears,
and the login page appears with a message indicating the logged-out state.
Interface Naming Conventions
Within the GUI, interfaces are denoted by linking the following elements:
•
Type of interface: The following types of interfaces are found on the switch:
o
Gigabit Ethernet ports (displayed as GE).
o
LAG (Port Channel) (displayed as LAG).
o
VLAN
•
Interface Number: Port, LAG or VLAN ID
Window Navigation
This section describes the features of the Web-based switch configuration utility.
Application Header
The Application Header appears on every page. It provides the following application links:
Application Link Name Description
Logout Click to log out of the Web-based switch configuration utility.
Firmware Version Display the device version number.
Help Click for the link to this administration guide.

Linksys LGS326P Specifications

General

Switch type	Managed
Switch layer	-
Quality of Service (QoS) support	Yes
Combo SFP ports quantity	2
Installed SFP+ modules quantity	0
Gigabit Ethernet (copper) ports quantity	26
Basic switching RJ-45 Ethernet ports type	Gigabit Ethernet (10/100/1000)
Basic switching RJ-45 Ethernet ports quantity	24
10G support	No
Number of VLANs	128
Networking standards	IEEE 802.1D, IEEE 802.1p, IEEE 802.1Q, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3af, IEEE 802.3az, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
Virtual LAN features	Tagged VLAN
Copper ethernet cabling technology	1000BASE-T, 100BASE-T, 10BASE-T
DHCP features	DHCP client
Security algorithms	802.1x RADIUS
Throughput	38.69 Mpps
Jumbo frames	9000
MAC address table	8000 entries
Product color	Black, Blue
LED indicators	Activity, Link, PoE, System
Number of fans	2 fan(s)
Memory type	DRAM
Internal memory	128 MB
Input current	3.5 A
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (typical)	28.58 W
Total Power over Ethernet (PoE) budget	192 W
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 50 °C
Operating relative humidity (H-H)	10 - 90 %

Weight and Dimensions

Depth	200 mm
Width	440 mm
Height	44 mm
Weight	3096 g
