Linksys LGS326P User Manual

7
Management Buttons
The following table describes the commonly used buttons that appear on various pages in the
system.
Button Name Description
Add
Click to display the related Add page and add an entry to a table.
Enter the information and click Apply to save it to the Running
Configuration. Click Close to return to the main page. Click
Save to display the Configuration File Copy page and save the
Running Configuration to the Startup Configuration file type
on the device.
Apply
Click to apply changes to the Running Configuration on the
device. If the device is rebooted, the Running Configuration is
lost unless it is saved to the Startup Configuration file type or
another file type. Click Save to display the Configuration File
Copy page and save the Running Configuration to the Startup
Configuration file type on the device.
Close
Click to return to the previous page. Any changes not applied
are cleared.
Clear All
Click to clear the statistic counters for all interfaces.
Clear
Click to clear information, such a counters of an interface, all
interface, or log files.
Delete
After selecting an entry in the table, click Delete to remove.
Edit
Select the entry and click Edit.
1. Click Apply to save the changes to the Running
Configuration.
2. Click Close to return to the main page.
Search
Enter the query filtering criteria and click Search.
Refresh
Click Refresh to refresh the counter values.
Test or Start
Click Test/Start to perform the related tests.
View or View All
Click View to display details associated with the entry
selected or for all entries (respectively).

Linksys LGS326P Specifications

General

Switch type	Managed
Switch layer	-
Quality of Service (QoS) support	Yes
Combo SFP ports quantity	2
Installed SFP+ modules quantity	0
Gigabit Ethernet (copper) ports quantity	26
Basic switching RJ-45 Ethernet ports type	Gigabit Ethernet (10/100/1000)
Basic switching RJ-45 Ethernet ports quantity	24
10G support	No
Number of VLANs	128
Networking standards	IEEE 802.1D, IEEE 802.1p, IEEE 802.1Q, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3af, IEEE 802.3az, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
Virtual LAN features	Tagged VLAN
Copper ethernet cabling technology	1000BASE-T, 100BASE-T, 10BASE-T
DHCP features	DHCP client
Security algorithms	802.1x RADIUS
Throughput	38.69 Mpps
Jumbo frames	9000
MAC address table	8000 entries
Product color	Black, Blue
LED indicators	Activity, Link, PoE, System
Number of fans	2 fan(s)
Memory type	DRAM
Internal memory	128 MB
Input current	3.5 A
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (typical)	28.58 W
Total Power over Ethernet (PoE) budget	192 W
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 50 °C
Operating relative humidity (H-H)	10 - 90 %

Weight and Dimensions

Depth	200 mm
Width	440 mm
Height	44 mm
Weight	3096 g
