CHAPTER 3: SETTING INTO OPERATION 21
TRYTON 107/112
The TRYTON 107/112 bar feeder is delivered as follows:
• The bar feeder is fully assembled and attached to the pallet with eight screws (A).
• A pusher is delivered installed in the bar feeder, and any additional accessories are delivered attached
to the mount (B).
• The interface outlet and technical documentation are packaged separately (C) with the mounting
supplies.
• Take out the accessories and supplies, then place them where they will be accessible once the bar
feeder has been installed.
