CHAPTER 3: SETTING INTO OPERATION 23
TRYTON 107/112
The distance between the lathe and the front of the bar feeder should not
exceed 20 mm. If an obstacle requires a greater distance, contact LNS
or its local representative.
The area around the lathe and the bar feeder must be cleared to allow for
their maintenance and handling. It should remain clear after the installation
is completed.
1.3.2. Lifting with a Forklift
To lift from below, spread the Forklift's lifting arms so as to be able to insert them between the feet and the
electrical box (shown below).
