CHAPTER 4: ELECTRICS 35
TRYTON 107/112
4.2.6. PLC inputs / outputs
Inputs Outputs
Input Des. Description Output Des. Description
I0
K8
Emergency stop control circuit
O32
KM1A
Advance hydraulic motor-pump
I1
SP1
Air pressure switch
O33
KM1R
Retract hydraulic motor-pump
I2 SP2
Hydraulic pressure control
switch
O34 KA2 Indexing motor
I3 SQ10
Loading arm safety switch
(option)
O35 KA3A Advance connector motor
I4
SQ11
Main access cover safety switch
O36
KA3R
Retract connector motor
I5 SQ1
Positioning stopper proximity
switch
O37 KA4 Pusher retract motor
I6 SQ2 Barrel indexing O38 YV10
Coupler valve : Pusher retract
cable
I7 SQ3
Indexing hole detector (option
hybrid)
O39 YV11 Barrel unlocking valve
I8 SQ4
Material presence control
proximity switch
O40 YV12 Position stop valve
I9
SQ5
Front end-of-travel connector
O41
YV13
Pneumatic front rest (option)
I10
SQ6
Rear end-of-travel connector
O42
YV14
Production control (option)
I11
SQ7
Locked piston
O43
YV15
Blocking section feed (option)
I12
SQ8
End of bar
O44
-
Not used
I13
SB20
Load push-button
O45
-
Not used
I14 SB21 Selector / Advance O46 - Not used
I15
SB22
Selector / Retract
O47
-
Not used
I16 SR1
Encoder forward or reverse
indicator (option)
O48 - Not used
I17 - Not used O49 - Not used
I18
SQ31
Production control (option)
O50
-
Not used
I19
-
Not used
O51
-
Not used
I20 SQ9
Detector: Positioning of control
SQ4
O52 - Not used
I21
SQ33
Long remnant (option)
O53
-
Start relay
I22
-
Not used
O54
-
Not used
I23
-
Not used
O55
-
Not used
Interface
Interface
I24
A1
Clamping device of the lathe
O56
R1
Relay : Bar feeder alarm
I25 A2 Lathe in Automatic cycle O57
R2 +
YV18
Relay : Loading cycle +
camshaft stopping valve (for
cam lathe type)
I26 A3 Load command O58
R3 +
YV19
Relay : End of Bar + spindle
stopper (for cam lathe type)
I27
A4
Workpiece load signal
O59
R4
Relay : automatic mode
I28
A5
Lathe door opened
O60
R5
Relay : auxiliary End of Bar
I29 A6 Reserve O61 R6 Reserve
I30
A7
Reserve
O62
R7
Reserve
I31
A8
Reserve
O63
R8
Reserve
