9.11. LONG TOTAL
Allows you to view and clear the long total for current products.
9.12. CLEAR ALL
Allows you to clear the long total for all products.
9.13. SELF TEST
This function tests various functions and the internal memory. All tests are run automatically when this option is selected. When
the test has completed, the Total screen will display.
9.14. UPLINK
This option is used to upload a configuration file created using Loadrite Toolbox via a Loadrite Data Module or from a PC via a
EDP cable. The configuration file contains product names, data lists and settings.
For information on creating a configuration file, refer to the Loadrite Toolbox User Manual.
9.14.1. Uploading a configuration file via a EDP cable
1) From the Uplink Menu select EDP, then press .
The Indicator will enter Uplink mode.
2) When the message Uplink Ready is displayed, use Loadrite Toolbox to send the configuration file.
The message Updating and a counter will display as the Indicator receives the configuration file.
Loadrite Toolbox will display a message to indicate that the upload is complete.
3) Press to exit Uplink mode.
9.14.2. Uploading a configuration file via a Loadrite Data Module
1) From the Uplink Menu select Data Module, then press .
2) Connect the Loadrite Data Module containing the configuration file to the Indicator.
3) When the Sync Config From Module? message displays, press .
A counter will display as the Indicator receives the configuration file.
4) When the Delete Config From Module? message displays, press .
The configuration file will be deleted from the Data Module.
9.15. STANDBY
This option puts the Indicator into Standby mode. The Indicator will also go into Standby mode if it is not used for two hours.
Press any button to exit Standby mode.
