Logan X90 - Page 106

12A-12
FUEL MIXTURE
Air filter unit
K7M, and 710
12A
REMOVAL
Remove the air filter unit mounting bolts (1).
Disconnect:
-the oil vapour rebreather pipe (2),
-the air inlet sleeve.
Remove the air filter unit.
REFITTING
Proceed in the reverse order to removal.
108423
107361
1
1
2
